DV-SP301
IC TERMINAL DESCRIPTION
139 CPU_CAS0 DRAM CAS 0 SDRAM_CAS/
CPU_ADR[22]
O
140 CPU_CAS1 DRAM CAS 1 NOT_SDRAM_CS0 O
141 CPU_DATA[0] Data[0] I/O
142 CPU_DATA[1] Data[1] I/O
143 CPU_DATA[2] Data[2] I/O
144 CPU_DATA[3] Data[3] I/O
145 CPU_DATA[4] Data[4] I/O
146 CPU_DATA[5] Data[5] I/O
147 CPU_DATA[6] Data[6] I/O
148 CPU_DATA[7] Data[7] I/O
149 VDD1_8 1.8V power supply Power
150 VSS Ground Power
151 CPU_DATA[8] Data[8] I/O
152 CPU_DATA[9] Data[9] I/O
153 CPU_DATA[10] Data[10] I/O
154 CPU_DATA[11] Data[11] I/O
155 CPU_DATA[12] Data[12] I/O
156 CPU_DATA[13] Data[13] I/O
Top side
157 CPU_DATA[14] Data[14] I/O
158 CPU_DATA[15] Data[15] I/O
159 VDD3_3 3.3 V power supply Power
160 VSS Ground Power
161 CPU_ADR[1] Address[1] O
162 CPU_ADR[2] Address[2] O
163 CPU_ADR[3] Address[3] O
164 CPU_ADR[4] Address[4] O
165 CPU_ADR[5] Address[5] O
166 CPU_ADR[6] Address[6] O
167 CPU_ADR[7] Address[7] O
168 CPU_ADR[8] Address[8] O
169 CPU_ADR[9] Address[9] O
170 CPU_ADR[10] Address[10] O
Pin
number
Pin name Main function
Alternate function
Pin
type
Input Outp
ut
PIN LIST SORTED BY FUNCTION 6
