Onkyo HT-R330 User Manual

4/38 PAGE
EXP
U05 AMPLIFIER PC board ass'y NAAF-8523-1B 1 1B068523-1B <DD, DC>
EXP
U05 AMPLIFIER PC board ass'y NAAF-8523-1C 1 1B068523-1C <WT, PP>
EXP
U06
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1B 1 1B068524-1B <DD, DC>
EXP
U06
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1C 1 1B068524-1C <WT, PP>
EXP
U08
THERMAL SENSOR PC board ass'y
NAETC-8526-1B 1 1B068526-1B <DD, DC>
EXP
U08
THERMAL SENSOR PC board ass'y
NAETC-8526-1C 1 1B068526-1C <WT, PP>
EXP
U09 HOLDER PC board ass'y NAETC-8527-1B 1 1B068527-1B
EXP
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1B 1 1B068544-1B <DD, DC>
EXP
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1C 1 1B068544-1C <WT>
EXP
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1K 1 1B068544-1K <PP>
EXP
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1B 1 1B068546-1B <DD, DC>
EXP
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1C 1 1B068546-1C <WT>
EXP
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1K 1 1B068546-1K <PP>
EXP
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1B 1 1B068547-1B <DD, DC>
EXP
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1C 1 1B068547-1C <WT>
EXP
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1K 1 1B068547-1K <PP>
EXP
U15
SPEAKER TERMINAL PC board ass'y
NAETC-8548-1B 1 1B068548-1B <DD, DC>
EXP
U15
SPEAKER TERMINAL PC board ass'y
NAETC-8548-1C 1 1B068548-1C <WT>
EXP
U15
SPEAKER TERMINAL PC board ass'y
NAETC-8548-1K 1 1B068548-1K <PP>
EXP
U16 VIDEO PC board ass'y NAVD-8549-1B 1 1B068549-1B <DD, DC>
EXP
U16 VIDEO PC board ass'y NAVD-8549-1C 1 1B068549-1C <WT>
EXP
U16 VIDEO PC board ass'y NAVD-8549-1K 1 1B068549-1K <PP>
EXP
U17
DRIVER AMPLIFIER PC board ass'y
NAAF-8550-1B 1 1B068550-1B <DD, DC>
EXP
U17
DRIVER AMPLIFIER PC board ass'y
NAAF-8550-1C 1 1B068550-1C <WT>
EXP
U17
DRIVER AMPLIFIER PC board ass'y
NAAF-8550-1K 1 1B068550-1K <PP>
EXP
U18 TUNER UNIT TFCE1U114B 1 240134A <DD, DC>
EXP
U18 TUNER UNIT TFCE1E512A 1 240135 <WT, PP>
HT-R330
PC BOARD PARTS LIST
U01 DISPLAY PC BOARD (NADIS-8513-1B/1C/1Z)
U02 DSP PC BOARD (NADG-8514-1B/1C/1Z)
U03 SWITCH PC BOARD (NASW-8515-1B/1C/1Z)
U04 HEADPHONE JACK PC BOARD (NAETC-8516-1B/1C/1Z)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
PCB1
U131 PHT CP GP1FAV51RKF5 1 24120129
PCB1
U821 REMO SENS GP1UM281XKVFH=16MM 1 241361
PCB1
Q111 IC BU1924FS 1 22242120R2 <PP>
PCB1
Q131 IC 74HCU04F 1 222740046R2
PCB1
Q151 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q151 or IC SN74AHC541PWR (1) 22274541IR2TI
PCB1
Q152 IC TC74HCT7007AF 1 222740077R2TO
PCB1
Q171 IC TC7WU04FU 1 22240935R2
PCB1
Q201 IC CS494003CQZ 1 22242039R3
PCB1
Q281 IC MX26LV040TC 1 W0037R301456M100
PCB1
Q401 IC NJM4580M-D 1 22241448R2
PCB1
Q402 IC NJM4580M-D 1 22241448R2
PCB1
Q403 IC NJM4580M-D 1 22241448R2
PCB1
Q421 IC CS42518-CQZR-D 1 22242229R2
PCB1
Q701 IC M30622MGP-236FPU0 1 22242250R3
