Onkyo HT-R330 User Manual

3/38 PAGE
EXP
Q6055 or TR MN130S-P (1) 2203666
EXP
Q6055 or TR MN130S-O (1) 2203663
EXP
Q6060 TR 2SA1941-O 1 2203053
EXP
Q6060 or TR 2SA1941-R (1) 2203052
EXP
Q6060 or TR MP130S-Y (1) 2203674
EXP
Q6060 or TR MP130S-P (1) 2203676
EXP
Q6060 or TR MP130S-O (1) 2203673
EXP
Q6061 TR 2SA1941-O 1 2203053
EXP
Q6061 or TR 2SA1941-R (1) 2203052
EXP
Q6061 or TR MP130S-Y (1) 2203674
EXP
Q6061 or TR MP130S-P (1) 2203676
EXP
Q6061 or TR MP130S-O (1) 2203673
EXP
Q6062 TR 2SA1941-O 1 2203053
EXP
Q6062 or TR 2SA1941-R (1) 2203052
EXP
Q6062 or TR MP130S-Y (1) 2203674
EXP
Q6062 or TR MP130S-P (1) 2203676
EXP
Q6062 or TR MP130S-O (1) 2203673
EXP
Q6063 TR KTA1962A-O 1 2203943
EXP
Q6063 or TR KTA1962A-R (1) 2203942
EXP
Q6063 or TR MP130S-Y (1) 2203674
EXP
Q6063 or TR MP130S-P (1) 2203676
EXP
Q6063 or TR MP130S-O (1) 2203673
EXP
Q6064 TR KTA1962A-O 1 2203943
EXP
Q6064 or TR KTA1962A-R (1) 2203942
EXP
Q6064 or TR MP130S-Y (1) 2203674
EXP
Q6064 or TR MP130S-P (1) 2203676
EXP
Q6064 or TR MP130S-O (1) 2203673
EXP
Q6065 TR KTA1962A-O 1 2203943
EXP
Q6065 or TR KTA1962A-R (1) 2203942
EXP
Q6065 or TR MP130S-Y (1) 2203674
EXP
Q6065 or TR MP130S-P (1) 2203676
EXP
Q6065 or TR MP130S-O (1) 2203673
EXP
<Note>
EXP
Must use the same HFE rank mutually about the following parts.
EXP
Ref. No. : Q6050 - 6060, Q6051 - 6061, Q6052 - 6062, Q6053 - 6063, Q6054 - 6064, Q6055 - 6065
EXP
T901 P TRANS NPT-1515D 1 2301796 !, <DD>
EXP
T901 P TRANS NPT-1515D 1 2301796 !, <DC>
EXP
T901 P TRANS NPT-1515DQ 1 2301797 !, <WT>
EXP
T901 P TRANS NPT-1515P 1 2301819 !, <PP>
EXP
U01 DISPLAY PC board ass'y NADIS-8513-1B 1 1B068513-1B <DD, DC>
EXP
U01 DISPLAY PC board ass'y NADIS-8513-1C 1 1B068513-1C <WT>
EXP
U01 DISPLAY PC board ass'y NADIS-8513-1Z 1 1B068513-1Z <PP>
EXP
U02 DSP PC board ass'y NADG-8514-1B 1 1B068514-1B <DD, DC>
EXP
U02 DSP PC board ass'y NADG-8514-1C 1 1B068514-1C <WT>
EXP
U02 DSP PC board ass'y NADG-8514-1Z 1 1B068514-1Z <PP>
EXP
U03 SWITCH PC board ass'y NASW-8515-1B 1 1B068515-1B <DD, DC>
EXP
U03 SWITCH PC board ass'y NASW-8515-1C 1 1B068515-1C <WT>
EXP
U03 SWITCH PC board ass'y NASW-8515-1Z 1 1B068515-1Z <PP>
EXP
U04
HEADPHONE JACK PC board ass'y
NAETC-8516-1B 1 1B068516-1B <DD, DC>
EXP
U04
HEADPHONE JACK PC board ass'y
NAETC-8516-1C 1 1B068516-1C <WT>
EXP
U04
HEADPHONE JACK PC board ass'y
NAETC-8516-1Z 1 1B068516-1Z <PP>
