Onkyo HT-R390 User Manual

52
En
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (North American)
110 watts minimum continuous power
per channel, 6 ohm loads, 1 channel
driven at 1 kHz, with a maximum total
harmonic distortion of 1% (FTC)
(Others)
1 ch × 100 W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
Maximum Effective Output Power
(Asian)
1 ch × 120 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
Rated RCA Output Level and Impedance
200 mV/2.2 kΩ (REC OUT)
Maximum RCA Output Level and Impedance
2 V/2.2 kΩ (REC OUT)
Frequency Response 20 Hz - 50 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
(North American and Brazilian)
87.5 MHz - 107.9 MHz
(Others) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American and Brazilian)
AC 120 V, 60 Hz
(European) AC 230 V, 50 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American and Brazilian) 3.5 A
(European) 320 W
(Others) 370 W
Stand-by Power Consumption
(North American and Brazilian) 0.2 W
(Others) 0.3 W
Dimensions
(W × H × D)
435 mm × 150 mm × 328 mm
17-1/8" × 5-7/8" × 12-15/16"
Weight (Korean) 7.6 kg (16.8 lbs)
(Asian) 7.7 kg (17.0 lbs)
(Others) 7.5 kg (16.5 lbs)
Input IN 1, IN 2, IN 3, IN 4
Output OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD)
Component IN 1, IN 2
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
AUX
Component OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Optical: 2
Coaxial: 1
Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,
TV/CD, AUX
Analog VCR/DVR
Speaker Outputs SP-A (L, R, C, SL, SR, SW) + SP-B (L, R)
Phones 1 (6.3 ø)
Universal Port 1
RI 1

Onkyo HT-R390 Specifications

General

Channels	5.1
Signal-to-Noise Ratio	100 dB (Line, IHF-A)
Speaker Impedance	6 ohms
HDMI Inputs	4
HDMI Outputs	1
Optical Inputs	2
Coaxial Inputs	1
USB Port	No
Bluetooth	No
Power Output	100 W per channel (6 ohms, 1 kHz, 1% THD)
Frequency Response	20 Hz–50 kHz
Input Sensitivity	200mV
Dolby Support	Dolby TrueHD, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
