1/37 PAGE
EXPLODED VIEW PARTS LIST
<Notes>
(S) : Silver model
(B) : Black model
(G) : Golden model
<402> : TX-SR402 (Chinese model)
<8240> : TX-SR8240 (Chinese model)
<420> : HT-R420 (All destination)
<DD> : HT-R420 (American model)
<DC> : HT-R420 (Canadian model)
<PA> : HT-R420 (Australian model)
<PT> : HT-R420 （Asian model 230-240V)
<WT> : HT-R420 （Worldwide model)
REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
EXP.
A002 SCREW 3TTF+8B(BC) 2 835430088
EXP.
A004 SCREW 3TTB+8B 1 838130088
EXP.
A005 SCREW 3TTB+10B(BC) 10 838430108
EXP.
A007 SCREW 3TTB+10B(BC) 3 838430108
EXP.
A010 CHASSIS --- 1 27100416A
EXP.
A015 HOLDER KGLS-8RT 1 27190503A
EXP.
A016 HOLDER KGPS-10RF 2 27190813
EXP.
A017 HOLDER KGLS-10RT 3 27190428A
EXP.
A020 SCREW 3TTB+8B 6 838130088
EXP.
A021 SCREW 3TTB+8B 4 838130088
EXP.
A022 SCREW 3TTB+8B 1 838130088
EXP.
A023 SCREW 4TTC+8C(BC) 4 830440089
EXP.
A024 SCREW 3TTB+8B 1 838130088
EXP.
A025 RIVET P-RIVET NRP-345 1 880009
EXP.
A026 SCREW 3TTW+8B(BC) 1 831430088
EXP.
A028 BUSHING S-RELIEF #2271 1 27300750 !
EXP.
A030 HEAT SINK AS 1 27160501
EXP.
A035 SCREW 3TTB+8B 1 838130088
EXP.
A036 SCREW 3TTB+8B 2 838130088
EXP.
A037 SCREW 3SMS8W.SW+14B(BC) 10 801433
EXP.
A050 COVER --- 1 28184831 (B)
EXP.
A050 COVER --- 1 28184856 (S)
EXP.
A050 COVER --- 1 28184857 (G)
EXP.
A051 SCREW 3TTB+8B(BC) 6 838430088 (B)
EXP.
A051 SCREW 3TTB+8B(UN) 6 838930088 (S), (G)
EXP.
A055 LEG LEG 4 27175319B
EXP.
A056 CUSHION --- 8 28141494
EXP.
A057 SCREW 3TTB+8B 4 838130088
EXP.
A060 KNOB (VOL)AS 1 28325643 (G) <8240>
EXP.
A060 KNOB (VOL)AS 1 28326198 (S) <402>, <420>
EXP.
A060 KNOB (VOL)AS 1 28326199 (G) <402>
EXP.
A060 KNOB (VOL)AS 1 28326197 (B) <420>
EXP.
A065 CLEAR PLT --- 1 28191958 (S),(G)
EXP.
A065 CLEAR PLT --- 1 28191957 (B)
EXP.
A401 REAR PANEL --- 1 27123218 <402>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
TX-SR402/8240/HT-R420
