Onkyo HT-R420

17/37 PAGE
PCB
P801 PLUG NPLG-14P666 1 25055710
PCB
E300 RETAINER KANAGU 1 27141059
PCB
PCB
U2 DISPLAY PC BOARD(NADIS-7403-3A/3B)
PCB
U3 SWITCH PC BOARD(NASW-7404-3A/3B)
PCB
U4 HEADPHONE JACK PC BOARD(NAETC-7405-3A/3B)
PCB
<Note> Parts are indicated collectively, without dividing for above-mentioned each substrate.
PCB
REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB
U7501 REMO SENS SPS-444-1-VP 1 241352
PCB
Q7501 FL TUBE 16BT123GK 1 212250
PCB
Q7501A HOLDER (FL) 1 27190989B
PCB
Q7502 IC MPD780232GC-030-8BT 1 22241571R3
PCB
Q7503 TR KTC3875-GR 1 2216175R2
PCB
Q7503 or TR 2SC2712-GR ( 1) 2213145R2
PCB
Q7504 TR KRA103S 1 2216230R2
PCB
Q7504 or TR RN2403 ( 1) 2214540R2
PCB
Q7506 TR KRC102S 1 2216190R2
PCB
Q7506 or TR RN1402 ( 1) 2214470R2
PCB
D7501 ZENER D UDZS8.2B 1 224550820R2
PCB
D7501 or ZENER D UDZ8.2B ( 1) 224490820R2
PCB
D7501 or ZENER D HZU8.2B ( 1) 224660824R2
PCB
D7502 ZENER D UDZS5.1B 1 224550510R2
PCB
D7502 or ZENER D UDZ5.1B ( 1) 224490510R2
PCB
D7502 or ZENER D HZU5.1B ( 1) 224660514R2
PCB
D7503 C-DIODE 1SS355 1 223269R2
PCB
D7503 or C-DIODE 1SS352 ( 1) 223234R2
PCB
D7505 LED SLR-56VRTB7 1 225431
PCB
D7505 or LED SEL4110R ( 1) 225290
PCB
D7507 C-DIODE 1SS355 1 223269R2
PCB
D7507 or C-DIODE 1SS352 ( 1) 223234R2
PCB
L7504 CHOKE COIL NCH-1477 1 231237K220R2
PCB
L7505 CHOKE COIL NCH-1477 1 231237K220R2
PCB
X7501 CERA LOCK CST5.00MGW 1 3010242
PCB
C253 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C261 C-CERA C CC725CH1H-101J1 1 342101014R1 <8240>, <402>
PCB
C261 C-CERA C CC725CH1H-101J1 1 342101014R1 <PA>, <WT>, <PT>
PCB
C261 C-CERA C CC725CH1H-471J1 1 342104714R1 <DD>, <DC>
PCB
C262 C-CERA C CC725CH1H-101J1 1 342101014R1 <8240>, <402>
PCB
C262 C-CERA C CC725CH1H-101J1 1 342101014R1 <PA>, <WT>, <PT>
PCB
C262 C-CERA C CC725CH1H-471J1 1 342104714R1 <DD>, <DC>
PCB
C263 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7501 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7502 ELECT C CE04W50V-33M 1 355783309T
PCB
C7503 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7504 C-CERA C CK725F1H-473Z1 1 332154730R1
PCB
C7505 C-CERA C CK725F1H-473Z1 1 332154730R1
PCB
C7506 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7507 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7508 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7509 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7510 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7511 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7513 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7514 VR C CE04W6.3V-100M(VR) 1 394621017
PCB
C7514 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017
PCB
C7515 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7516 C-CERA C CK725F1E-104Z1 1 332161040R1
