1/38 PAGE
HT-R540
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
<DD> : USA model
<DC> : Canadian model
<PA> : Australian model
EXPLODED VIEW PARTS LIS
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
A001 F BRACKET --- 1 27111442 (B)
EV
A001 F BRACKET --- 1 27111444 (S)
EV
A002 SCREW 3TTB+8B(3CM)SR 5 801637
EV
A004 CUSHION --- 1 28141686
EV
A011 SCREW 3TTB+8B(3CM)SR 3 801637
EV
A012 SCREW 3TTB+8B(3CM)SR 2 801637
EV
A013 WIRE TIE BSK-1 7 260208
EV
A015 CHASSIS --- 1 --- NSP
EV
A016 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A017 WIRE TIE BINDER(CLAMPER)UL 2 260258
EV
A018 HOLDER KGLS-22S 1 27190369
EV
A020 HOLDER KGLS-16RT 2 27190511
EV
A021 HOLDER HOLDER 4 27190991
EV
A022 HOLDER KGLS-10RT 1 27190428A
EV
A024 SCREW 3TTB+8B(3CM)SR 3 801637
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
To Next Page
