Onkyo HT-R580(B) - Pc Board Parts List

RL6902 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
HT-R580
PC BOARD PARTS LIST
U003
DG-AS(MPU/DAC AS)
U0030+U0031
BADG-0364-1AE * 1 1B247564-1AE N <B CMMO, CMMQ>
U003
DG-AS(MPU/DAC AS)
U0030+U0031
BADG-0364-1M * 1 1B247564-1M N <B CMDC, CMDD>
U0030 DG-AS
(
MPU/DAC
)
BADG-0364-1AE 1 1B2475364-1AE N <B CMMO, CMMQ>
U0030 DG-AS
(
MPU/DAC
)
BADG-0364-1M 1 1B2475364-1M N <B CMDC, CMDD>
U0031 PWB
(
U PORT
)
BAETC-0365-1AE 1 1B2475365-1AE N <B CMMO, CMMQ>
U0031 PWB
(
U PORT
)
BAETC-0365-1M 1 1B2475365-1M N <B CMDC, CMDD>
CIRCUIT. N PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 NSP
D110 or C-DIODE 1SS352 ( 1) NSP
D110 or C-DIODE MA2J111 ( 1) NSP
D111 C-DIODE KDS4148U 1 NSP
D111 or C-DIODE 1SS352 ( 1) NSP
D111 or C-DIODE MA2J111 ( 1) NSP
D112 ZENER D UDZS10B 1 224551000R2 <B CMMO, CMMQ>, <B CMDC, CMDD>
D131 C-DIODE KDS4148U 1 NSP
D131 or C-DIODE 1SS352 ( 1) NSP
D131 or C-DIODE MA2J111 ( 1) NSP
D132 C-DIODE KDS4148U 1 NSP
D132 or C-DIODE 1SS352 ( 1) NSP
D132 or C-DIODE MA2J111 ( 1) NSP
D182 DIODE RL1N4003 1 22380260T
D183 DIODE RL1N4003 1 22380260T
D601 C-DIODE KDS4148U 1 NSP
D601 or C-DIODE 1SS352 ( 1) NSP
D601 or C-DIODE MA2J111 ( 1) NSP
D701 C-DIODE KDS4148U 1 NSP
D701 or C-DIODE 1SS352 ( 1) NSP
D701 or C-DIODE MA2J111 ( 1) NSP
D702 C-DIODE KDS4148U 1 NSP
D702 or C-DIODE 1SS352 ( 1) NSP
D702 or C-DIODE MA2J111 ( 1) NSP
Q101 IC LC72725KV-TLM-E 1 22242584R2 <B CMMO, CMMQ>
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T <B CMMO, CMMQ>, <B CMDC, CMDD>
Q131 IC TC74HCU04AF 1 222740046R2TO
