Onkyo HT-R580(B) - Parts Lists; Diodes and ICs

P751A SOCKET IMSA-9618S-09A 1 25053334R2
P8001A PLUG IMSA-9111B-16 1 25056620
P8002A PLUG IMSA-9111B-24 1 25056625
HT-R580
PC BOARD PARTS LIST
U004
DIS-AS(DISPLAY AS)
U0040+U0041+U0042+U0042+U004
3+U0044
BADIS-0373-1J * 1 1B247573-1J N <B CMDC, CMDD>
U004
DIS-AS(DISPLAY AS)
U0040+U0041+U0042+U0042+U004
3+U0044
BADIS-0373-1U * 1 1B247573-1U N <B CMMO, CMMQ>
U0040 DIS-AS
(
DISPLAY
)
BADIS-0373-1J 1 1B2475373-1J N <B CMDC, CMDD>
U0040 DIS-AS
(
DISPLAY
)
BADIS-0373-1U 1 1B2475373-1U N <B CMMO, CMMQ>
U0041 PWB
(
STANDBY KEY/LED
)
BADIS-0374-1J 1 Included in "REF,NO, U004
0
N <B CMDC, CMDD>
U0041 PWB
(
STANDBY KEY/LED
)
BADIS-0374-1U 1 Included in "REF,NO, U004
0
N <B CMMO, CMMQ>
U0042 PWB
(
VIDEO AS
)
BAVD-0375-1J 1 1B2475375-1J N <B CMDC, CMDD>
U0042 PWB
(
VIDEO AS
)
BAVD-0375-1U 1 1B2475375-1U N <B CMMO, CMMQ>
U0043 PWB
(
POW SUPPLY
)
BAETC-0376-1J 1 1B2475376-1J N <B CMDC, CMDD>
U0043 PWB
(
POW SUPPLY
)
BAETC-0376-1U 1 1B2475376-1U N <B CMMO, CMMQ>
U0044 PWB
(
HP JACK
)
BAETC-0377-1J 1 1B2475377-1J N <B CMDC, CMDD>
U0044 PWB
(
HP JACK
)
BAETC-0377-1U 1 1B2475377-1U N <B CMMO, CMMQ>
CIRCUIT. N PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U7041 REMO SENS KSM-603TE5B 1 24130019
[SEMI CONDUCTOR]
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7151 LED SLI-343URC-TE7 1 225449T
D7152 LED SLI-343Y8C-TE7 1 225490T N
D7153 LED SLR-342MGTE7P 1 225455T <B CMDC, CMDD>, <B CMMO, CMMQ>
D7301 C-DIODE KDS4148U 1 NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D7301 or C-DIODE 1SS352 ( 1) NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D7301 or C-DIODE MA2J111 ( 1) NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D7302 C-DIODE KDS4148U 1 NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D7302 or C-DIODE 1SS352 ( 1) NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D7302 or C-DIODE MA2J111 ( 1) NSP <B CMDC, CMDD>, <B CMMO, CMMQ>
D9011 DIODE D5SBA20 1 22380130F <B CMDC, CMDD>, <B CMMO, CMMQ>
D9014 C-DIODE KDS4148U 1 NSP
D9014 or C-DIODE 1SS352 ( 1) NSP
D9014 or C-DIODE MA2J111 ( 1) NSP
D9015 C-DIODE KDS4148U 1 NSP
D9015 or C-DIODE 1SS352 ( 1) NSP
D9015 or C-DIODE MA2J111 ( 1) NSP
D9016 ZENER D UDZS6.2B 1 224550620R2 <B CMDC, CMDD>, <B CMMO, CMMQ>
D9023 C-DIODE KDS4148U 1 NSP
