A265 TAPE TAPE(CLOTH-8U) 1 29110082
A269 TAPE TAPE(CLOTH-8U) 1 29110082
A270 CUSHION (FELT)t1x20x10 4 28141859
A271 TAPE TAPE(CLOTH-16U) 1 29110083
A273 HOLDER KGLS-4S 2 27190009
A321 KNOB (VOL)AS(B) 1 28326914
A340 COVER (B) (Bent) 1 28210089A
A340 COVER (B) (Not Bent) 1 28210089AZ
A342 SCREW 3TTB+8B(3BC) 9 838430088GR
A350 PLATE (COVER)B 1 27262881
A354 HOLDER (PLATE) 6 27191337
A360 LABEL (COVER) 1 29390767
A362 LABEL HOOKUP-ONKYO 1 29363194 <B MDC, MDD>
[TRANS COIL]
T901 P TRANS NPT-1604D 1 2302012
!
<B MDC, MDD, MDS>
T901 P TRANS NPT-1604M 1 2302014
!
<B MMK, MMQ>
[SW TRM]
F6401 FUSE 10A-UL/T-233 1 252330GR
!
F6401 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F6402 FUSE 10A-UL/T-233 1 252330GR
!
F6402 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F901 FUSE 4A-SE-EAK 1 252077GR
!
<B MMK, MMQ>
F901 FUSE 8A-UL/T-233 1 252329GR
!
<B MDC, MDD, MDS>
F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR
!
<B MDC, MDD, MDS>
F901 or FUSE 4A-SE-TL250V ( 1) 252277GR
!
<B MMK, MMQ>
F901E LABEL LABEL 1 29360842 <B MDC, MDD, MDS>
F901E LABEL T4AL250V 1 29361732A <B MMK, MMQ>
P101 FFC NCFC7-091512 1 2047091512
P2800 FFC NCFC5-091012 1 2045091012
P3101 SOCKET AS NSAS-10P1924 1 2009991224UL
P6601A P RIVET JB-407A-C 14 880052 <B MMK, MMQ>
P701 FFC NCFC5-232212 1 2045232212
P703 FFC NCFC5-072512 1 2045072512
P8001 FFC NCFC5-291022 1 2045291022
P8004 FFC NCFC5-072512 1 2045072512
P901 AC CORD AS-BS 1 253198LTK
!
<B MMQ>
P901 AC CORD AS-CEE-2 1 253306VOL
!
<B MMK>
P901 AC CORD AS-UC-2 1 253368AYUN
!
<B MDC, MDD>
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK
!
<B MDC, MDD>
P901 or AC CORD AS-CEE-2 ( 1) 253374YUN
!
<B MMK>
P901B FASTON AS FASTON SOCKET 1 1F999027
!
<B MDS>
P907 AC INLET R301X2PSn 1 25053358
!
<B MDS>
[TUNER UNIT]
U001 U0010 ～
～～
～ U0014 BAAF-1070-1F * 1 1B272570-1F N <MDC, MDS>
U0010 AUDIO PC BOARD ASS'Y BAAF-1070-1F 1 1B2725070-1F N <MDC, MDF>
U0011 SENSOR PC BOARD ASS'Y BAETC-1072-1F 1 1B2725072-1F N <MDC, MDF>
U0012 FIX PC BOARD BAETC-1073-1F 1 1B2725073-1F N <MDC, MDF>
U0013 TERMINAL PC BOARD ASS'Y BAETC-1074-1F 1 1B2725074-1F N <MDC, MDF>
U0014 POWER SUPPLY(VP) PC BOARD ASS'Y BAETC-1075-1F 1 1B2725075-1F N <MDC, MDF>
U001 U0010 ～
～～
～ U0014 BAAF-1070-1G * 1 1B272570-1G N <MMQ, MMK>
U0010 AUDIO PC BOARD ASS'Y BAAF-1070-1G 1 1B2725070-1G N <MMQ, MMK>
U0011 SENSOR PC BOARD ASS'Y BAETC-1072-1G 1 1B2725072-1G N <MMQ, MMK>
U0012 FIX PC BOARD BAETC-1073-1G 1 1B2725073-1G N <MMQ, MMK>
U0013 TERMINAL PC BOARD ASS'Y BAETC-1074-1G 1 1B2725074-1G N <MMQ, MMK>
U0014 POWER SUPPLY(VP) PC BOARD ASS'Y BAETC-1075-1G 1 1B2725075-1G N <MMQ, MMK>
U002 U0020 x 4 pcs. BACLA-1130-2C * 1 1B271530-2C N
U0020 AMPLIFIER PC BOARD ASS'Y BACLA-1130-2C 1 1B2715130-2C N
U003 U0030 ～
～～
～ U0034 x 2 pcs. BATRM-1089-1F * 1 1B272589-1F N <MDC, MDS>
U0030 SPEAKER TERMINAL PC BOARD ASS'Y BATRM-1089-1F 1 1B2725089-1F N <MDC, MDS>
U0032 TERMINAL(DIGITAL) PC BOARD ASS'Y BAETC-1091-1F 1 1B2725091-1F N <MDC, MDS>
U0033 CONNECTOR PC BOARD ASS'Y BAETC-1092-1F 1 1B2725092-1F N <MDC, MDS>
U0034 FIX PC BOARD BAETC-1100-1F 1 1B2725100-1F N <MDC, MDS>
U003 U0030 ～
～～
～ U0034 x 2 pcs. BATRM-1089-1G * 1 1B272589-1G N <MMQ, MMK>
U0030 SPEAKER TERMINAL PC BOARD ASS'Y BATRM-1089-1G 1 1B2725089-1G N <MMQ, MMK>
U0032 TERMINAL(DIGITAL) PC BOARD ASS'Y BAETC-1091-1G 1 1B2725091-1G N <MMQ, MMK>
U0033 CONNECTOR PC BOARD ASS'Y BAETC-1092-1G 1 1B2725092-1G N <MMQ, MMK>
U0034 FIX PC BOARD BAETC-1100-1G 1 1B2725100-1G N <MMQ, MMK>
U004 U0040 ～
～～
～ U0044 BADIS-0654-3E * 1 1B271554-3E N <MDC, MDS>
U0040 DISPLAY PC BOARD ASS'Y BADIS-0654-3E 1 1B2715654-3E N <MDC, MDS>
