U0041 SWITCH PC BOARD ASS'Y BADIS-0655-3E 1 1B2715655-3E N <MDC, MDS>
U0042 VIDEO PC BOARD ASS'Y BAVD-0656-3E 1 1B2715656-3E N <MDC, MDS>
U0043 PHONE JACK PC BOARD ASS'Y BAETC-0658-3E 1 1B2715658-3E N <MDC, MDS>
U0044 POWER SUPPLY PC BOARD ASS'Y BAPS-0659-3E 1 1B2715659-3E N <MDC, MDS>
U004 U0040 ～
～～
～ U0044 BADIS-0654-3F * 1 1B271554-3F N <MMQ, MMK>
U0040 DISPLAY PC BOARD ASS'Y BADIS-0654-3F 1 1B2715654-3F N <MMQ, MMK>
U0041 SWITCH PC BOARD ASS'Y BADIS-0655-3F 1 1B2715655-3F N <MMQ, MMK>
U0042 VIDEO PC BOARD ASS'Y BAVD-0656-3F 1 1B2715656-3F N <MMQ, MMK>
U0043 PHONE JACK PC BOARD ASS'Y BAETC-0658-3F 1 1B2715658-3F N <MMQ, MMK>
U0044 POWER SUPPLY PC BOARD ASS'Y BAPS-0659-3F 1 1B2715659-3F N <MMQ, MMK>
U005 U0050 x 2 pcs. BAHDM-1126-1A * 1 1126-1A_HTR591MDC N <MDC, MDS>
U0050 HDMI(MAIN) PC BOARD ASS'Y BAHDM-1126-1A 1 1B2715126-1A_R591MDC N <MDC, MDS.
U005 U0050 x 2 pcs. BAHDM-1126-1A * 1 1126-1A_HTR591MMK N <MMK, MMQ>
U0050 HDMI(MAIN) PC BOARD ASS'Y BAHDM-1126-1A 1 1B2715126-1A_R591MMQ N <MMK, MMQ>
U010 TUNER UNIT FAEH08-W01 1 240169A <B MDC, MDD, MDS>
U010 TUNER UNIT FAEH08-E01 1 240170A <B MMK, MMQ>
HT-R591
PACKING PROCEDURES PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A601 PAD AS (AS)HTR390 L&R 1 29092582A
A601A PAD (L) 1 29092583A
A601B PAD (R) 1 29092584A
A605 POLY BAG w850xd650 1 29100245
A606 TAPE (SEROHAN)NITTO NO.29 1 29110149
A608 SHEET T0.5x600x500 1 29096097
A611 TAPE (SEROHAN)NITTO NO.29 1 29110149
A672 POLY BAG w250xd350 1 29100250A <B MDC, MDD, MMK, MMQ>
A704A LABEL (DES)HTR591_C(B)MDC 1 29391884
N
<B MDC>
A704A LABEL (DES)HTR591_C(B)MDD 1 29391885
N
<B MDD>
A704A LABEL (DES)HTR591_C(B)MDS 1 29391886
N
<B MDS>
A704A LABEL (DES)HTR591_C(B)MMQ 1 29391887
N
<B MMQ>
A704A LABEL (DES)HTR591_C(B)MMK 1 29391888 <B MMK>
HT-R591
PC BOARD PARTS LIST
U001
U0010 ～
～～
～ U0014 BAAF-1070-1F/1G *
U0010 AUDIO PC BOARD ASS'Y BAAF-1070-1F/1G
U0011 SENSOR PC BOARD ASS'Y BAETC-1072-1F/1G
U0012 FIX PC BOARD BAETC-1073-1F/1G
U0013 TERMINAL PC BOARD ASS'Y BAETC-1074-1F/1G
U0014 POWER SUPPLY(VP) PC BOARD ASS'Y BAETC-1075-1F/1G
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4173 ZENER D DZ2J068M0L 1 224760680R2
D4173 or ZENER D UDZS6.8B ( 1) 224550680R2
D4174 ZENER D DZ2J068M0L 1 224760680R2
D4174 or ZENER D UDZS6.8B ( 1) 224550680R2
D4207 C-DIODE DA2J10100 1 223303R2
D4207 or C-DIODE 1SS352 ( 1) 223234R2
D4207 or C-DIODE 1SS355 ( 1) 223269R2
D4207 or C-DIODE MA2J111 ( 1) 223279R2
D4207 or C-DIODE KDS4148U ( 1) 223283R2
D4217 C-DIODE DA2J10100 1 223303R2
D4217 or C-DIODE 1SS352 ( 1) 223234R2
D4217 or C-DIODE 1SS355 ( 1) 223269R2
D4217 or C-DIODE MA2J111 ( 1) 223279R2
D4217 or C-DIODE KDS4148U ( 1) 223283R2
D4300 DIODE RL1N4003 1 22380260T
D4300 or DIODE GP104003E ( 1) 22380035T
D4301 DIODE RL1N4003 1 22380260T
D4301 or DIODE GP104003E ( 1) 22380035T
D4302 DIODE RL1N4003 1 22380260T
