TX-NR525/HT-R592/HT-RC550
OPERATION CHECK-2
1.OPERATION CHECK(2/2)
Monitor out
A
B
C
D
E
1-9. CONFIRMATION OF OSD(ON SCREEN DISPLAY) OPERATION
a. When SETUP(HT-R592) or HOME(TX-NR525/HT-RC550) button is pushed, confirm that setup menu
is displayed in HDMI Out.
b. Confirm that specified operations for ENTER(with 4-cursor) buttons are made.
1-10. CONFIRMATION OF HDMI AUDIO OPERATION.
See “OPERATION CHECK-3,-6” for TEST MODE operation.
a. CO
NFIRMATION OF HDMI I2S SIGNAL
1. Input the one of these signals below from HDMI1 terminal.
DTS-HD MasterAudio 7.1ch
Dolby TrueHD 7.1ch
2. Change the state to TEST 6-00. Confirm the signal is output from L/R,SW/C,SL/SR,SBL/SBR.
3. When TEST 6-08, confirm the sound(HDMI1 input) outputs from the TV.
b. CONFIRMATION OF HDMI SPDIF SIGNAL
4. SPDIF signal is input from HDMI terminal.
5. When TEST 6-06, confirm the sound(HDMI IN1) outputs from the speaker.
6. When TEST 6-07, confirm the sound(BD/DVD analog input) outputs from the TV.(VIDEO is Blue back.)
c. CONFIRMATION OF HDMI DSD SIGNAL.
7. When TEST 6-10,11,12, confirm the sound of DSD 5.1ch input HDMI IN 3, output from the speaker.
1-11. VIDEO FUNCTION CHECK
See “OPERATION CHECK-3,-6” for TEST MODE operation.
a. Confirm Video output signal as shown Table 2, while Video signal are input as shown Table 1.
NOTE 1: Confirm the HDMI path at 1080p signal.
Table 1
Input
BD/DVD
VCR/DVR
CBL/SAT
GAME
AUX
Composite Video
A
B
C
D
E
Component
IN1
---
IN2
---
---
F
---
G
---
---
HDMI
IN1
IN2
IN3
IN4
---
H
I
J
K
---
Test mode
5-05(BD/DVD)
5-06(VCR/DVR)
5-07(CBL/SAT)
5-08(GAME)
5-10(AUX)
Composite Video
VCR out
A
---
C
D
E
Component
OUT
F
---
G
---
---
HDMI
OUR
H
I
J
K
---
Table 2
b. OPERATIONS OF VIDEO SIGNAL-DETECTION
1. Confirm "RDS" light up on FL TUBE when component video signal is input in "TEST 5-00".
Confirm "RDS" turn off on FL TUBE when component video signal isn't input in "TEST 5-00",too.
2. Confirm "FM STEREO" light up on FL TUBE when component video signal is input in "TEST 5-00".
Confirm "FM STEREO" turn off on FL TUBE when component video signal isn't input in "TEST 5-00",too.
1-12. MISCELLANEOUS
a. Confirm all input and output terminals operate normally.
b. Please confirm LED and FL displaying by the FL TEST mode. And confirm the destination setting.
---> See to “OPERATION CHECK-3”.
c. Change the state to KEY TEST under TEST MODE to confirm each key operation.
---> See to“OPERATION CHECK-3”.
d. Confirm the version of each firmware.
---> See to “SERVICE PROCEDURE-2”.
e. Confirm the firmware combination check.
---> See to “OPERATION CHECK-3”.
Applied to HT-R592
Applied to TX-NR525/HT-RC550.
Table 1
Input
BD/DVD
IN2
CBL/SAT
GAME
PC
AUX
Composite Video
A
---
B
C
D
E
Component
IN1
---
IN2
---
---
---
F
---
G
---
---
---
HDMI
IN1
IN2
IN3
IN4
IN5
IN6
H
I
J
K
L
M
Test mode
5-05(BD/DVD)
5-06(IN2)
5-07(CBL/SAT)
5-08(GAME)
5-09(PC)
5-10(AUX)
Composite Video
Monitor out
A
-
B
C
D
E
Component
OUT
F
---
G
---
---
---
HDMI
OUR
H
I
J
K
L
M
Table 2
To Next Page
