9/84 PAGE
U005 SP terminal pc board AS BATRM-0029-1E 1 1B232529-1E <MO>
U010 TUNER UNIT FAEH06-E01EX 1 240165 <MO>
U010 TUNER UNIT FAEH06-A01US 1 240166 <DC>
HT-R670
HT-R670
PC BOARD PARTS LIS
U001 Input selector/Volume/Power amp. pc board AS (BAAF-0008-1F/G)
U0011 Trans 2nd terminal pc board AS (BAPS=0009-1F/G)
U0012 Trans 2nd terminal pc board AS (BAPS-0010-1F/G)
U0013 Thermal sensor pc board AS (BAETC-0011-1F/G)
U0014 Holder pc board AS (BAETC-0012-1F/G)
U0015 Holder pc board AS (BAETC-0013-1F/G)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
[SEMI CONDUCTOR]
D5000 ZENER D MTZJ5.6B 1 224470562T
D5001 ZENER D MTZJ5.6B 1 224470562T
D5002 ZENER D MTZJ5.6B 1 224470562T
D5003 ZENER D MTZJ5.6B 1 224470562T
D5004 ZENER D MTZJ5.6B 1 224470562T
D5005 ZENER D MTZJ5.6B 1 224470562T
D5006 ZENER D MTZJ5.6B 1 224470562T
D5671 ZENER D MTZJ6.2B 1 224470622T
D5672 ZENER D MTZJ6.2B 1 224470622T
D5673 DIODE 1SS133 1 223163T
D5674 DIODE 1SS133 1 223163T
D5707 C-DIODE KDS4148U 1 223283R2
D5707 or C-DIODE 1SS352 ( 1) 223234R2
D5707 or C-DIODE MA2J111 ( 1) 223279R2
D5708 C-DIODE KDS4148U 1 223283R2
D5708 or C-DIODE 1SS352 ( 1) 223234R2
D5708 or C-DIODE MA2J111 ( 1) 223279R2
