8/84 PAGE
A350 PLATE (COVER) 1 27262834A
A354 HOLDER (PLATE) 8 27191337
A360 LABEL (COVER) 1 29390767
A362 LABEL HOOKUP-ONKYO 1 29363194 <DC>
[TUNER UNIT]
U001 Input selector/Volume/Power amp. pc board AS BAAF-0008-1G 1 1B232508-1G N <DC>
U0011 Trans 2nd terminal pc board AS BAPS-0009-1G 1 NSP
<DC>
U0012 Trans 2nd terminal pc board AS BAPS-0010-1G 1 NSP
<DC>
U0013 Thermal sensor pc board AS BAETC-0011-1G 1 NSP
<DC>
U0014 Holder pc board AS BAETC-0012-1G 1 NSP
<DC>
U0015 Holder pc board AS BAETC-0013-1G 1 NSP
<DC>
U001 Input selector/Volume/Power amp. pc board AS BAAF-0008-1F 1 1B232508-1F <MO>
U0011 Trans 2nd terminal pc board AS BAPS-0009-1F 1 NSP <MO>
U0012 Trans 2nd terminal pc board AS BAPS-0010-1F 1 NSP <MO>
U0013 Thermal sensor pc board AS BAETC-0011-1F 1 NSP <MO>
U0014 Holder pc board AS BAETC-0012-1F 1 NSP <MO>
U0015 Holder pc board AS BAETC-0013-1F 1 NSP <MO>
U002 MPU/CODEC pc board AS BADG-0025-1G 1 1B232525-1G N <DC>
U0021 Universal port pc board AS BAETC-0027-1G 1 NSP
<DC>
U002 MPU/CODEC pc board AS BADG-0025-1D 1 1B232525-1D <MO>
U0021 Universal port pc board AS BAETC-0027-1D 1 NSP
<MO>
U003 Diplay pc board AS BADIS-0036-1G 1 1B232536-1G <DC>
U0031 Switch pc board AS BADIS-0037-1G 1 NSP <DC>
U0032 Video pc board AS BAVD-0038-1G 1 NSP <DC>
U0033 Power supply pc board AS BAPS-0039-1G 1 NSP <DC>
U0034 Headphone pc board AS BAETC-0040-1G 1 NSP <DC>
U003 Diplay pc board AS BADIS-0036-1J 1 1B232536-1J <MO>
U0031 Switch pc board AS BADIS-0037-1J 1 NSP <MO>
U0032 Video pc board AS BAVD-0038-1J 1 NSP <MO>
U0033 Power supply pc board AS BAPS-0039-1J 1 NSP <MO>
U0034 Headphone pc board AS BAETC-0040-1J 1 NSP <MO>
U004 HDMI / DSP pc board AS BAHDM-0060-1A 1 1B232560-1A
