U0034 Headphone pc board AS (BAETC-0040-1G/1J)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
[TUNER UNIT]
U7042 REMO SENS NJL34H380A 1 241365
[SEMI CONDUCTOR]
D2084 ZENER D UDZS6.8B 1 224550680R2
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7152 LED SLI-343URC-TE7 1 225449T
D7154 LED SCB3318E-D2 1 225487
N
<MO>
D7155 LED SLR-342MGTE7P 1 225455T
D7301 C-DIODE KDS4148U 1 223283R2
D7301 or C-DIODE 1SS352 ( 1) 223234R2
D7301 or C-DIODE MA2J111 ( 1) 223279R2
D7302 C-DIODE KDS4148U 1 223283R2
D7302 or C-DIODE 1SS352 ( 1) 223234R2
D7302 or C-DIODE MA2J111 ( 1) 223279R2
D7401 ZENER D UDZS5.1B 1 224550510R2
D7411 ZENER D UDZS6.8B 1 224550680R2
D7412 ZENER D UDZS6.8B 1 224550680R2
D9001 DIODE RL1N4003 1 22380260T
D9005 ZENER D UDZS36B 1 224553600R2
D9011 DIODE D5SBA20 1 22380130F
D9014 C-DIODE KDS4148U 1 223283R2
D9014 or C-DIODE 1SS352 ( 1) 223234R2
D9014 or C-DIODE MA2J111 ( 1) 223279R2
D9015 C-DIODE KDS4148U 1 223283R2
D9015 or C-DIODE 1SS352 ( 1) 223234R2
D9015 or C-DIODE MA2J111 ( 1) 223279R2
D9016 ZENER D UDZS5.6B 1 224550560R2 <DC>
D9016 ZENER D UDZS6.8B 1 224550680R2 <MO>
D9023 C-DIODE KDS4148U 1 223283R2
