T901 P TRANS NPT-1590D 1 2301974 ! <B C2MDC, CMDC>
[SW TRM]
F6901 FUSE 10A-UL/T-233 1 252330GR ! <B C2MDC, CMDC>
F6901 or FUSE 10A-T/UL-ST2 ( 1) 252333GR ! <B C2MDC, CMDC>
F6902 FUSE 10A-UL/T-233 1 252330GR ! <B C2MDC, CMDC>
F6902 or FUSE 10A-T/UL-ST2 ( 1) 252333GR ! <B C2MDC, CMDC>
F901 FUSE 8A-UL/T-233 1 252329GR ! <B C2MDC, CMDC>
F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR ! <B C2MDC, CMDC>
P101 FFC NCFC7-111512 1 2047111512 <B>
P2801 FFC NCFC7-091012 1 2047091012 <B>
P701 FFC NCFC7-312012 1 2047312012 <B>
P901 AC CORD AS-UC-2 1 253368AYUN ! <B C2MDC, CMDC>
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK ! <B C2MDC, CMDC>
[TUNER UNIT]
U001
AF-AS(Amplifier Asy)
U0010+U0011+U0012+U0013+U0014
BAAF-0348-1A * 1 1B247548-1A N <B C2MDC, CMDC>
U0010 AF-ASAF-AS(Amplifier Asy) BAAF-0348-1A 1 1B2475348-1A N <B C2MDC, CMDC>
U0011 PWB(FL Tube -VP) BAPS-0349-1A 1 1B2475349-1A N <B C2MDC, CMDC>
U0012 PWB(Thermal Senser) BAETC-0350-1A 1 1B2475350-1A N <B C2MDC, CMDC>
U0013 WB(Thermal Senser FIX) BAETC-0351-1A 1 N, NSP <B C2MDC, CMDC>
U0014 PWB(Trans Terminal FIX) BAETC-0352-1A 1 1B2475352-1A N <B C2MDC, CMDC>
U003
DG-AS(MPU DIR DAC U-port Asy)
U0030+U0031
BADG-0364-1Q * 1 1B247564-1Q N <B C2MDC, CMDC>
U0030 DG-AS(MPU DIR DAC Asy) BADG-0364-1Q 1 1B2475364-1Q N <B C2MDC, CMDC>
U0031 PWB(U-port) BAETC-0365-1Q 1 1B2475365-1Q N <B C2MDC, CMDC>
U004
DIS-AS(Disply Video Pow-supply HP Asy)
U0040+U0041+U0042+U0043+U0044
BADIS-0373-1K * 1 1B247573-1K N <B C2MDC, CMDC>
U0040 DIS-AS(Disply Video Pow-supply HP Asy) BADIS-0373-1K 1 1B2475373-1K N <B C2MDC, CMDC>
U0041 PWB(Stadby-Key/ LED) BADIS-0374-1K 1 Included in "REF,NO, U004
N <B C2MDC, CMDC>
U0042 PWB(Video Asy) BAVD-0375-1K 1 1B2475375-1K N <B C2MDC, CMDC>
U0043 PWB(Power Supply Asy) BAETC-0376-1K 1 1B2475376-1K N <B C2MDC, CMDC>
U0044 PWB(HP-Jack Asy) BAETC-0377-1K 1 1B2475377-1K N <B C2MDC, CMDC>
U006
TRM-AS(Speakers Terminal Asy)
U0060+U0061
BATRM-0368-1A * 1 1B247568-1A N <B C2MDC, CMDC>
U0060 TRM-AS(Speakers Terminal Asy) BATRM-0368-1A 1 1B2475368-1A N <B C2MDC, CMDC>
U0064 PWB(reserve) BAETC-0372-1A 1 N, NSP <B C2MDC, CMDC>
U007 HDM-AS(HDMI Asy) BAHDM-0403-1A * 1 1B247503-1A N <B C2MDC, CMDC>
U010 TUNER UNIT FAEH06-A01US 1 240166 <B C2MDC, CMDC>
