Onkyo HT-R680(B) - Pc Board Parts List

RL6902 RELAY NRL-1P10A-DC12-196 1 25065707 N
RL6902 o RELAY NRL-1P10A-DC12-197 ( 1) 25065708 N
RL6902 o RELAY NRL-1P10A-DC12-198 ( 1) 25065709
HT-R680
PC BOARD PARTS LIS
T
U003
DG-AS(MPU DIR DAC U-port Asy)
U0030+U0031
BADG-0364-1Q * 1 1B247564-1Q N <B C2MDC, CMDC>
U0030 DG-AS(MPU DIR DAC Asy) BADG-0364-1Q 1 1B2475364-1Q N <B C2MDC, CMDC>
U0031 PWB(U-port) BAETC-0365-1Q 1 1B2475365-1Q N <B C2MDC, CMDC>
CIRCUIT PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 NSP
D110 or C-DIODE 1SS352 ( 1) NSP
D110 or C-DIODE MA2J111 ( 1) NSP
D111 C-DIODE KDS4148U 1 NSP
D111 or C-DIODE 1SS352 ( 1) NSP
D111 or C-DIODE MA2J111 ( 1) NSP
D112 ZENER D UDZS10B 1 224551000R2 <B C2MDC, CMDC>
D131 C-DIODE KDS4148U 1 NSP
D131 or C-DIODE 1SS352 ( 1) NSP
D131 or C-DIODE MA2J111 ( 1) NSP
D132 C-DIODE KDS4148U 1 NSP
D132 or C-DIODE 1SS352 ( 1) NSP
D132 or C-DIODE MA2J111 ( 1) NSP
D182 DIODE RL1N4003 1 22380260T
D183 DIODE RL1N4003 1 22380260T
D601 C-DIODE KDS4148U 1 NSP
D601 or C-DIODE 1SS352 ( 1) NSP
D601 or C-DIODE MA2J111 ( 1) NSP
D701 C-DIODE KDS4148U 1 NSP
D701 or C-DIODE 1SS352 ( 1) NSP
D701 or C-DIODE MA2J111 ( 1) NSP
D702 C-DIODE KDS4148U 1 NSP
D702 or C-DIODE 1SS352 ( 1) NSP
D702 or C-DIODE MA2J111 ( 1) NSP
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T <B C2MDC, CMDC>
Q131 IC TC74HCU04AF 1 222740046R2TO
Q131 or IC 74HCU04F ( 1) 222740046R2
Q153 IC R1EX25064ASA00A 1 22242581R2
Q153 or IC M95640-WMN6TP ( 1) 22242643R2 N
Q181 TR KRC105S 1 2217290R2
