Onkyo HT-R680(B) User Manual

Q181 or TR RN1405 ( 1) 2214500R2
Q2804 IC NJM4580M-D 1 22241448R2
Q301 IC PCM9210PTR 1 22242629R2 N
Q302 IC PCM1690DCAR 1 22242599R2
Q401 IC NJM4580M-D 1 22241448R2
Q402 IC NJM4580M-D 1 22241448R2
Q403 IC NJM4580M-D 1 22241448R2
Q404 IC NJM4580M-D 1 22241448R2 <B C2MDC, CMDC>
Q405 IC NJM4580M-D 1 22241448R2 <B C2MDC, CMDC>
Q601 TR KRC104S 1 2216210R2
Q601 or TR RN1404 ( 1) 2214490R2
Q701 IC (MMPU)
MPD70F3746(03530)IC(FLASH
1 222W0079R303530
Q702 IC S-812C33AUA-C2N 1 22242222R2
Q703 IC S-812C56AUA-C3K 1 22242207R2
Q704 IC SN74CB3Q3305PWR 1 22242258R2
Q746 IC XC6221B332MR 1 22242633R2
Q751 TR KRC104S 1 2216210R2
Q751 or TR RN1404 ( 1) 2214490R2
Q752 TR KRA102S 1 2216220R2
Q752 or TR RN2402 ( 1) 2214530R2
Q753 TR KRA107S 1 2216350R2
Q753 or TR RN2407(TE85L_F) ( 1) 2216360R2
Q754 TR KRC102S 1 2216190R2
Q754 or TR RN1402 ( 1) 2214470R2
Q755 TR KRA107S 1 2216350R2
Q755 or TR RN2407(TE85L_F) ( 1) 2216360R2
Q756 TR KRC102S 1 2216190R2
Q756 or TR RN1402 ( 1) 2214470R2
Q757 TR KRC107S 1 2216340R2
Q757 or TR RN1407 ( 1) 2216260R2
Q761 TR KRC104S 1 2216210R2 <B C2MDC, CMDC>
Q761 or TR RN1404 ( 1) 2214490R2 <B C2MDC, CMDC>
Q762 TR KRA102S 1 2216220R2 <B C2MDC, CMDC>
Q762 or TR RN2402 ( 1) 2214530R2 <B C2MDC, CMDC>
Q771 TR KRC104S 1 2216210R2 <B C2MDC, CMDC>
Q771 or TR RN1404 ( 1) 2214490R2 <B C2MDC, CMDC>
Q772 TR KRA102S 1 2216220R2 <B C2MDC, CMDC>
Q772 or TR RN2402 ( 1) 2214530R2 <B C2MDC, CMDC>
[TRANS COIL]
L131 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L132 CHOKE COIL LBC2518T2R2M 1 231364M022R2 <B C2MDC, CMDC>
L133 CHOKE COIL LBC2518T470M 1 231364M470R2
L134 CHOKE COIL LBC2518T470M 1 231364M470R2
