Onkyo HT-R960 Service Manual

TX-SR606
DEBUG MODE-8
HDMI TROUBLESHOOT-2/3
The Input assigned
to HDMI is not
selected now
Audio trouble
No sound Bad sound
Digital input is
OPT or
COAXIAL
No digital audio
signal on HDMI
Change to the
input assigned
to HDMI
Change
1-3.Digital Audio
Input to HDMI
Check the digital
audio output
setting of player
Change the
digital audio
output to HDMI
No sound on
specific
channnel
Short sound
drop at
the beginning
of music
Sound not on
AV speakers
but on TV
Sound drop
during music play
Check speaker
config.
No sound on
specific channels
according to
listening mode
HDMI takes
longer time in
identifying
audio format
Check HDMI
Control (CEC)
setting of TX-SR606
and TV
TV is in
Standby Mode
STB is YAGI
DTC10 or
compatibles
Change all
speakers
connected to
Yes
Check the support
tables of
Listening mode /
Audio format
in TX-SR606
owner’s manual
Normal
Change CEC
settings of
TX-SR606 and
TV
Power on TV
or enable iLINK
This STB does
not comply
with HDMI
clock system
Example :
Hitachi TV
Change STB or
consult with
STB maker
Confirm again
TX-SR606’s
Input Assign
1-1. HDMI Input
This trouble shooting map focuses on the audio setups and connections regarding HDMI.
For reference, read TX-SR606 Owner’s Manual.
Analysis written below is of typical cases. So, more detailed check may need in actual cases.
HDMI AUDIO SETUP TROUBLE
