1/81 PAGE
HT-RC160
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. *1 : Single model only
*2 : System model only
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TR 2SC4468-O 1 2202523
Q6050 or TR 2SC4468-Y ( 1) 2202524
Q6050 or TR 2SC4468-P ( 1) 2202526
Q6050 or TR MN130S-O ( 1) 2203663
Q6050 or TR MN130S-Y ( 1) 2203664
Q6050 or TR MN130S-P ( 1) 2203666
Q6050A ISO SHEET AC238 2 223024
Q6050B ISO SHEET ISO SHEET 6 223050
Q6051 TR 2SC4468-O 1 2202523
Q6051 or TR 2SC4468-Y ( 1) 2202524
Q6051 or TR 2SC4468-P ( 1) 2202526
Q6051 or TR MN130S-O ( 1) 2203663
Q6051 or TR MN130S-Y ( 1) 2203664
Q6051 or TR MN130S-P ( 1) 2203666
Q6052 TR 2SC4468-O 1 2202523
Q6052 or TR 2SC4468-Y ( 1) 2202524
Q6052 or TR 2SC4468-P ( 1) 2202526
Q6052 or TR MN130S-O ( 1) 2203663
Q6052 or TR MN130S-Y ( 1) 2203664
Q6052 or TR MN130S-P ( 1) 2203666
Q6053 TR 2SC4468-O 1 2202523
Q6053 or TR 2SC4468-Y ( 1) 2202524
Q6053 or TR 2SC4468-P ( 1) 2202526
Q6053 or TR MN130S-O ( 1) 2203663
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
To Next Page
