Onkyo HT-RC160 Service Manual

21/81 PAGE
P7903 PIN JACK NPJ-4PDWWRR624 1 25045845
P7903 or PIN JACK NPJ-4PDBL162 ( 1) 25045303
P7904 PIN JACK NPJ-4PDWWRR624 1 25045845
P7904 or PIN JACK NPJ-4PDBL162 ( 1) 25045303
P7905 PIN JACK NPJ-4PDWWRR624 1 25045845
P7905 or PIN JACK NPJ-4PDBL162 ( 1) 25045303
P7907 PIN JACK NPJ-4PDWRP682 1 25045914
RL6901 RELAY NRL-1P10A-DC12-140 1 25065584
RL6901 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
RL6902 RELAY NRL-1P10A-DC12-140 1 25065584
RL6902 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
U002 MPU/CODEC pc board AS (BADG-0025-1R)
U0021 Universal port pc board AS (BAETC-0027-1R)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U131 or PHT CP GP1FAV51RK0F ( 1) 24120129
U132 PHT CP JSR1165-001recieving 1 24120143
U132 or PHT CP GP1FAV51RK0F ( 1) 24120129
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 223283R2
D110 or C-DIODE 1SS352 ( 1) 223234R2
D110 or C-DIODE MA2J111 ( 1) 223279R2
D111 C-DIODE KDS4148U 1 223283R2
D111 or C-DIODE 1SS352 ( 1) 223234R2
D111 or C-DIODE MA2J111 ( 1) 223279R2
D112 ZENER D UDZS10B 1 224551000R2
D131 C-DIODE KDS4148U 1 223283R2
D131 or C-DIODE 1SS352 ( 1) 223234R2
D131 or C-DIODE MA2J111 ( 1) 223279R2
D132 C-DIODE KDS4148U 1 223283R2
D132 or C-DIODE 1SS352 ( 1) 223234R2
D132 or C-DIODE MA2J111 ( 1) 223279R2
D181 C-DIODE KDS4148U 1 223283R2
D181 or C-DIODE 1SS352 ( 1) 223234R2
