Onkyo HT-RC630 Basic Manual

2
About the Basic Manual
The Basic Manual leads you through the fundamental steps
to enjoy the AV Receiver from connections to TV, speaker
system and playback devices, to necessary functions for
playback. As well as that, Basic Manual informs you with
the instructions on frequently used functions. Besides, there
is another part of the manual called Advanced Manual to
inform you with more detailed information, which we have
decided to publish on the web from the ecological point of
view.
Advanced Manual
Advanced Manual is always updated with the latest
information and its user friendly interface, which does not
matter whether you access from PC or Smartphone, helps
you to understand more deeply about the AV Receiver.
Advanced Manual is consisted of the following chapters.
r AM/FM Radio Receiving Function
r Playing music files on a USB storage device
r Operating music files with the remote controller
r Listening modes
r Advanced settings
r Operating other components with the remote controller
r Connecting and operating Onkyo RI components
r Firmware update
r Troubleshooting
r Reference information
Advanced Manual found here
http://www.onkyo.com/manual/htrc630/adv/en.html
Features
r Equipped with 5-channel amplifier
r Equipped with 4K/60 Hz Passthrough-compatible HDMI
IN/OUT jacks
r Supports the HDMI Through function which allows
transmission from playback devices to the TV in standby
state
r Supports ARC (Audio Return Channel)
r Supports playback of USB storage device
r Supports Bluetooth connection
r A/V Sync Function to correct deviation of audio and
video
r Multi-zone function which allows you to play a different
source in another room from the main room
r 32 bit DSP (Digital Signal Processor) with excellent
calculation performance
r Music Optimizer™ for compressed digital music files
r Phase Matching Bass System
r Supports playback of MP3, FLAC, WAV, Ogg Vorbis,
Apple Lossless and DSD music files via USB storage
device
Supplied Accessories
Indoor FM antenna --- (1)
AM loop antenna --- (1)
3
2
1
Speaker Cable
Color labels for speaker cable --- (1)
Remote controller (RC-879M) --- (1)
Batteries (AA/R6) --- (2)
¼
The number in parenthesis indicates the quantity. On packaging, the letter
at the end of the product name indicates the color.
How to use the remote controller
Batteries (AA/R6)
Remote control sensor
#DQWV|HV
(5 m)
AV Receiver
¼
If you do not use the remote controller for a long time, remove the batteries
to prevent leakage.
¼
Note that keeping consumed batteries inside may cause corrosion resulting
in damage of the remote controller.
Before Start

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
