Onkyo HT-RC660(B)

59/59 PAGE
[SEMI CONDUCTOR]
1
Q1 HYBRID IC RZ5B801-0001E2 1 22242835R2
[TRANS COIL]
1
L1 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L2 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L3 RF COIL SDCL1608CR33JTDF 1 233557R1
1
L3 or RF COIL HK1608R33J-T ( 1) 233559R1
1
L4 RF COIL SDCL1608CR10JTDF 1 233556R1
1
L4 or RF COIL HK1608R10J-T ( 1) 233558R1
1
L5 ANTENNA COIL K7-D 1 232212
1
X1 CRYSTAL HC-49S 9B12.000MHz 1 3010533
[CAPACITOR]
1
C1 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C12 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-090D1 1 342100902R1
1
C13 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C2 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-220J1 1 342102204R1
1
C3 CHIP TYPE CERAMIC CAPACITOR CK725B1H-332K1 1 332103325R1
1
C4 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-100D1 1 342101002R1
1
C5 CHIP TYPE CERAMIC CAPACITOR CK725B1H-473K1 1 332104735R1
1
C6 CHIP TYPE CERAMIC CAPACITOR CK725B1H-222K1 1 332102225R1
1
C7 CHIP TYPE CERAMIC CAPACITOR CK725B1A-105K1 1 332131055R1
1
C8 CHIP TYPE CERAMIC CAPACITOR CK725B1A-105K1 1 332131055R1
1
C9 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 1 332071065R2
[RESISTOR]
1
R10 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R11 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R13 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R14 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R2 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R21 CHIP TYPE CARBON RESISTOR RN72K2E-000JE 1 435220004R1
1
R22 CHIP TYPE CARBON RESISTOR RN72K2E-000JE 1 435220004R1
1
R3 EMI SUPPRESSION FILTER BK1608HS601-T 1 230984R1
1
R4 EMI SUPPRESSION FILTER BK1608HS601-T 1 230984R1
1
R5 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R6 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R7 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R8 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R9 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
[SW TRM]
1
P1 TERMINAL NTM-1PDSC437 1 25060515
1
P101A SOCKET NSCT-7P2100 1 25052203
1
P2 TERMINAL NTM-2PDML439 1 25060517
