Onkyo HT-RC660(B) User Manual

Input selector DIGITAL COMPO- Volume HDMI
INPUT NENT
NonTHX/THX
5-00 BD/DVD HDMI - 31/51 IN1 DISC-D(BD) Tr.20or28
5-01 CBL/SAT HDMI IN 31/51 IN2 DISC-D(BD) Tr.21 or A(DVD)
5-02 STB/DVR HDMI - 31/51 IN3 DISC-D(BD) Tr.21 or A(DVD)
5-03 GAME HDMI - 31/51 IN4 DISC-D(BD) Tr.21 or A(DVD)
5-04 PC HDMI - 31/51 IN5 DISC-D(BD) Tr.21 or A(DVD)
5-05 IN6 HDMI - 31/51 IN6 DISC-D(BD) Tr.21 or A(DVD)
5-06
IN7 HDMI - 31/51 IN7 DISC-D(BD) Tr 21 or A(DVD)
IN8 HDMI - 31/51 IN8 DISC-D(BD) Tr 21 or A(DVD)
5-07 AUX HDMI - 31/51 AUX DISC-D(BD) Tr.21 or A(DVD)
5-08 CBL/SAT - IN1 MIN - -
5-09 CBL/SAT - - MIN - -
BD/DVD
- - MIN -
5-10 PC(RGB) - - MIN -
5-11 PC/GAME HDMI - 31/51 IN5/IN4
6-00 BD/DVD HDMI IN 40/60 IN3 DISC-C(SACD) TRACK12
6-01 BD/DVD COAX1* IN MIN - -
6-02
CBL/SAT HDMI ARC - 40/60 - -
6-03 BD/DVD HDMI - 31/51 IN1 -
6-04 BD/DVD HDMI - 31/51 IN1 -
6-05 BD/DVD HDMI - 31/51 IN1 -
Through(Man/Sub or Zone2_Both), SPDIF
Through(Man/Sub or Zone2_Both), SPDIF
HDMI OUT is blue back
Reference TEST DISC*
Z2 HDMI TEST / HDMI Powered Z2
RGB INPUT ? HDMI OUT
Audio out TV = ON
Through(Man/Sub or Zone2_Both), SPDIF
HDMI DSD SIGNAL
MODE
etc.
SP ALLch & SW-PO
SP ALLch & SW-PO
Audio out TV = ON
Through(Main/Sub or Zone2 Both), I2S
Audio out TV = ON
Through(Man/Sub or Zone2_Both), SPDIF
Audio out TV = ON
Through(Man/Sub or Zone2_Both), SPDIF
Through(Man/Sub or Zone2_Both), SPDIF
Through(Man/Sub or Zone2_Both), SPDIF
COMPONENT?HDMI(Main/Sub or Zone2_Both)
CEC Relay
check
MHL Check(CABLE DET)
Audio out TV = ON
Audio out TV = ON
OUTPUT CH =
L/R/C/SW/SL/SR
CV ? CV COMPONENT
CV ? HDMI(Main/Sub or Zone2_Both)
Through(Man/Sub or Zone2_Both), SPDIF
Audio out TV = ON
MHL Check(VBUS=ON)
MHL Check(VBUS=OFF)
HDMI AUDIO RETURN CHANNEL
Audio TV OUT = ON, VOL=0,
ANALOG(DVD)
CEC Relay
check
<NOTES>
1. DSP Thru of Listening Mode outputs L Input signal to L/C/SL/SBL, and outputs R Input signal to R/SR/SBR/SW.
2. Config. is in order of SW/Front/Center/Surround/Surround back.
3. Mute is function to stop output(from the channel) by using inner DSP programming.
4. When Listening Mode is DSP thru, an analog SW is changed into the state of SURROUND.
5. At the time of PRTCTTHM detection, it is displayed on FLT as "THERMAL PROTECT".
6. In all test modes, it is not concerned with detection of VOLH but SEC1H are made "H" fixation. (Except TEST 1-07 and 1-08.)
7. After initialization of Net or USB, start TEST 1-04. Afrer TEST 1-04 checking , clear the set.
Following frequencies are automatically written in the preset memory, when the unit goes into "TEST 3-00".
PRESET No. MD* MP*,MG* MJJ
MW*(10k) MW*(9k)
1 89.9MHz 89.90MHz 89.90MHz 76.0MHz
2 97.9MHz 97.90MHz 97.90MHz 82.0MHz
3 98.9MHz 98.90MHz 98.90MHz 83.0MHz
4 107.1MHz 107.10MHz 107.10MHz 84.0MHz
FM 5 107.9MHz 107.90MHz 107.90MHz 90.0MHz
6 100.1MHz 100.10MHz 100.10MHz 80.0MHz
7 88.1MHz 88.10MHz 88.10MHz 85.1MHz
8 104.1MHz 104.10MHz 104.10MHz 88.1MHz
9 95.3MHz 95.30MHz 95.30MHz 76.0MHz
10 106.7MHz 106.70MHz 106.70MHz 90.0MHz
11 530KHz 530KHz 522KHz 522kHz
12 630KHz 630KHz 630KHz 630kHz
13 990KHz 990KHz 990KHz 990kHz
14 1440KHz 1440KHz 1440KHz 1440kHz
AM 15 1710KHz 1710KHz 1611KHz 1611kHz
16 670KHz 670KHz 666KHz 666kHz
17 830KHz 830KHz 828KHz 828kHz
18 1310KHz 1310KHz 1314KHz 1314kHz
19 1200KHz 1200KHz 1197KHz 1197kHz
20 530KHz 530KHz 522KHz 522kHz
21 87.5MHz 87.50MHz 87.50MHz 76.0MHz
FM 22 107.9MHz 108.00MHz 108.00MHz 90.0MHz
23 103.7MHz 104.00MHz 104.00MHz 79.8MHz
24 104.5MHz 104.20MHz 104.20MHz 80.2MHz
AM 25 1180kHz 1180kHz 1179kHz 1179kHz
26 1220kHz 1220kHz 1215kHz 1215kHz
TEST-3-00
Video & HDMI Test mode
TX-NR636/ 737/ 838/ HT-RC660/ HT-R993/ DTR-30.6/ 40.6/ 50.6
OPERATION CHECK-9
