Q6066 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6066 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6066 or TRANSISTOR 2SA1941-R ( 1) 2203052
[CHASSIS SCREW]
A003 LEG (B) 4 27175464
A005 CUSHION (ZUL) 4 28141877
A090A LABEL (E-CON) { 1} 29364978
A101 REAR PANEL (HTRC660MDC) 1 27124604 N
A129 LABEL (SP7Ch+Z2) 1 29392523
[CABINET]
A201 FRONT PANEL HTRC660(B)DC 1 27213735 N
A203 CLEAR PLATE 636(B)D 1 28192426A
A205 BADGE 1 28135317
A207 KNOB (TONE)(B) 1 28326918
A209 KNOB (INP)B_737 1 28327166A
A211 KNOB (SEL) 1 28326906B
A213 KNOB (INP-L)B_737 1 28327168A
A215 KNOB (INP-R)B_737 1 28327169A
A216 FACET (KNOB)_737 2 28200075
A217 KNOB (STBY)(B) 1 28327234
A217 or KNOB (STBY)(B) ( 1) 28326904
A219 KNOB (CUR) 1 28326907B
A221 KNOB (VOL)AS(B) 1 28326933
A401 COVER (B) (Bent) 1 28210087B
A401 COVER (B) (Not Bent) 1 28210087BZ
A411 LABEL (CAUTION) 1 29392531
[TRANS COIL]
T901 POWER TRANSFORMER NPT-1640D 1 2302091 !
[SW TRM]
F6401 FUSE 12A-TUL-250V 1 252301GR !
F6402 FUSE 12A-TUL-250V 1 252301GR !
F9002 FUSE 10A-UL/T-233 1 252330GR !
F9002 or FUSE 10A-T/UL-ST2 ( 1) 252333GR !
P101 FLEXIBLE FLAT CABLE NCFC7-071012 1 2047071012
P2510 FAN KF1225B1E-33ACFG9RB 1 24502336
P2800 FLEXIBLE FLAT CABLE NCFC5-171012 1 2045171012
P701 FLEXIBLE FLAT CABLE NCFC5-232212 1 2045232212
P8651 CORD ASSEMBLY HDMI 0.25M 1 2010515
P9001 POWER SUPPLY CORD AS-UC-2 1 253368AYUN !
P9001 or POWER SUPPLY CORD AS-UC-2 ( 1) 253368BLTK !
[TUNER UNIT]
U001 U0010, U0011, U0012 BAAF-1511-1C * (Parent) 1 1B299511-1C MDC
U0010 AMP/ ASP PC BOARDS AS BAAF-1511-1C (Child) 1 1B2995511-1C
U0011 SENSOR(THERMAL) PC BOARDS AS BAETC-1512-1C (Child) 1 1B2995512-1C
U0012 FIX(THERMAL) PC BOARDS AS BAETC-1513-1C (Child) 1 1B2995513-1C
U002 U0020 x 30 pcs. BAAMP-1367-2A * (Parent) 1 1B299567-2A MDC
U0020 TRANSISTOR(AMP) PC BOARDS AS BAAMP-1367-2A (Child) 1 1B2995367-2A
U003 U0030, U0031, U0032 x 2 pcs. BACLA-1575-1A * (Parent) 1 1B299575-1A MDC
U0030 AMP(CLASS A) PC BOARDS AS BACLA-1575-1A (Child) 1 1B2995575-1A
U0031 FIX(HDMI CABLE) PC BOARDS AS BAETC-1573-1A (Child) 1 1B2995573-1A
U0032 FIX(FFC) PC BOARDS AS BAETC-1577-1A (Child) 1 1B2995577-1A
U004 U0040, U0041, U0042, U0043, U0044, U0045 BADIS-1530-1A * (Parent) 1 1B299530-1A MDC
U0040 DISPLAY PC BOARDS AS BADIS-1530-1A (Child) 1 1B2995530-1A
U0041 KEY/ LED PC BOARDS AS BASW-1531-1A (Child) 1 1B2995531-1A
U0042 DAC/ FILTER PC BOARDS AS BADG-1532-1A (Child) 1 1B2995532-1A
U0043 POWER SUPPLY(PRI) PC BOARDS AS BAPS-1533-1A (Child) 1 1B2995533-1A
U0044 PHONE JACK PC BOARDS AS BAETC-1534-1A (Child) 1 1B2995534-1A
U0045 CONNECTOR PC BOARDS AS BAETC-1535-1A (Child) 1 1B2995535-1A
U005 U0050, U0051 x 2 pcs. BATRM-1568-1A * (Parent) 1 1B299568-1A MDC
U0050 TERMINAL(SPEAKER) PC BOARDS AS BATRM-1568-1A (Child) 1 1B2995568-1A
U0051 FIX(FRONT HDMI) PC BOARDS AS BAETC-1569-1A (Child) 1 1B2995569-1A
U008 U0080 BAPRC-1564-1W * (Parent) 1 1B299564-1W MDC
U0080 PROCESSING(DSP/VSP/MPU/DAC) PC BOARDS AS BAPRC-1564-1W (Child) 1 1B2995564-1W
U009 U0090 x 25 pcs. BARF-1567-1A * (Parent) 1 1B299567-1A MDC
U0090 CONNCTOR(Wifi)/ BPF PC BOARDS AS BARF-1567-1A (Child) 1 1B2995567-1A
U010 U0100 x 25 pcs. BAHDM-1586-1A * (Parent) 1 1B299586-1A MDC
U0100 TERMINAL(FRONT HDMI) PC BOARDS AS BAHDM-1586-1A (Child) 1 1B2995586-1A
