3. If the unit is connected to the pre-main amplier in the separate room, adjust
the volume on the pre-main amplier. If the unit is connected to the power
amplier or ZONE speaker in the separate room, adjust the volume on the
remote controller.
• When connecting the power amplier, set "Zone B Output Level" to
"Variable" for "Speaker Setup" in the Initial Setup section ( p94). When
setting "Zone B Output Level" from the Setup menu, press on the remote
controller, and set "2. Speaker" - "Conguration" - "Zone B Output Level"
( p82) to "Variable". If it is not set, a large volume is output and the
power amplier, speakers, etc. may be damaged.
If "ZONE A+B" is selected as an audio output destination, you can select only
the "Stereo" listening mode for the main room (ZONE A) when using the 2.1ch
speaker layout. When using a speaker layout of 3.1ch or more, you can select
only the "AllCh Stereo" listening mode.

Onkyo HT-S5910 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
4Ω speaker support	No
Audio output channels	5.1.2 channels
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	115 W
Display	LCD
Product color	Black
Audio decoders	Dolby Atmos
Damping factor	60
Amplifier output power	925 W
HDMI in	4
Composite video in	3
Digital audio coaxial in	1
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	0
Audio (L/R) out	7
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	328 mm
Width	453 mm
Height	160 mm
Weight	7800 g
