Onkyo HT-S780 User Manual

58
Specification
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
■ AV Receiver (HT-R530)
Power Output
2 channel driven: North American:
110 W + 110 W (8 Ω , 1 kHz, FTC)
European:
110 W + 110 W (8
Ω , 1kHz, DIN)
Ohters:
130 W + 130 W (8
Ω , 1kHz, JEITA)
Dynamic Power 230 W + 230 W (3
Ω ,Front)
170 W + 170 W (4
Ω ,Front)
120 W + 120 W (8
Ω ,Front)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front,1kHz,8
Ω )
Input Sensitivity and
Impedance 200 mV/ 47 k
Ω (LINE)
Output Level and
Impedance 200 mV/ 470
Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 8
Ω –
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
Ω (Component and S-Video Y)
0.7 Vp-p /75
Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75
Ω (S-Video C)
1 Vp-p /75
Ω (Composite)
Component Video
Frequency Response 5 Hz – 50 MHz
Tuning Frequency
Range North American: 87.5 MHz– 107.9 MHz
Other: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo:17.2 dBf 2 µV(75
Ω IHF)
Mono: 11.2 dBf 1 µV(75
Ω IHF)
Signal to Noise Ratio Stereo: 70 dB (IHF-A)
Mono:76 dB (IHF-A)
THD Stereo: 0.3% (1kHz)
Mono:0.2% (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB (1kHz)
Tuning Frequency
Range North American: 530 kHz–1710 kHz
Others: 522 kHz–1611 kHz
Usable Sensitivity 30 µV
Signal to Noise Ratio 40 dB
THD 0.70%
Power Supply North American: AC 120 V, 60 Hz
Australian: AC 230-240 V, 50 Hz
Power Consumption North American: 6.3 A
Others: 650 W
Stand-by Power
Consumption North American: 0.1 W
Others: 0.2 W
Dimensions
(W
× H × D) 435 × 150 × 374 mm
17-1/8" × 5-7/8" × 14-3/4"
Weight North American: 9.4 kg
20.7 lbs.
Others: 10.2 kg
22.5 lbs.
Component DVD,VIDEO1,VIDEO2
S-Video DVD,VIDEO1,VIDEO2
Composite DVD,VIDEO1,VIDEO2,VIDEO3
Component MONITOR
S-Video MONITOR OUT,VIDEO1
Composite MONITOR OUT,VIDEO1
Digital Inputs Optical: 3
Coaxial: 1
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
VIDEO2,VIDEO3,TAPE,CD
Multichannel Inputs 6
Analog Outputs TAPE,VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs SP A (L, R, C, SL, SR, SBL, SBR)
SP B (L, R)
Phones 1
HT-S780En.book Page 58 Monday, February 28, 2005 2:13 PM
