Onkyo P-3000R Service Manual

30/55 PAGE
U001
R907 METAL O R RS1WBJ-470 1 443624714T
U001
R909 METAL R RNU1/2WCJ-1 1 453530104T
U001
R910 METAL R RNU1/2WCJ-1 1 453530104T
U001
[SW TRM]
U001
P1006B PLUG IDC 2.54-26P(S) 1 25056678
U001
P1010B PLUG NPLG-15P143 1 25055159
U001
P101A PLUG IMSA-9115B-07 1 25056337
U001
P101B SOCKET IMSA-9115S-07L 1 25052987
U001
P102A PLUG IMSA-9115B-07 1 25056337
U001
P102B SOCKET IMSA-9115S-07L 1 25052987
U001
P103A PLUG IMSA-9115B-05 1 25056335
U001
P103B SOCKET IMSA-9115S-05L 1 25052985
U001
P104A PLUG IMSA-9115B-05 1 25056335
U001
P104B SOCKET IMSA-9115S-05L 1 25052985
U001
P105 TRM-423(SCREW) NEJITANSI ST3 1 25060495
U001
P106 TRM-423(SCREW) NEJITANSI ST3 1 25060495
U001
P107 TRM(SCREW) NEJITANSI M3 1 25065425
U001
P108 TRM(SCREW) NEJITANSI M3 1 25065425
U001
P301 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P302 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P303 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P304 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P305 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P306 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P307 PLUG NPLG-5P220 1 25055236
U001
P311A PLUG IMSA-9115B-13 1 25056343 N <B MDC, MPP>
U001
P311B SOCKET IMSA-9115S-13L 1 25052993 N <B MDC, MPP>
U001
P312 TRM-423(SCREW) NEJITANSI ST3 1 25060495 <B MDC, MPP>
U001
P401 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P402 PIN JACK NPJ-2PDWR706 1 25045940A
U001
P410 RETAINER (BUS-BAR) 1 27142221
U001
P601 ST JACK MSJ-064-05A SR 1 25045783
U001
P601A RETAINER (EARTH) 1 27142220
U001
P602A SOCKET AS NSAS-30P1920 1 200C4293005UL N
U001
P602B PLUG NPLG-15P143 1 25055159
U001
P603A SOCKET AS NSAS-10P1921 1 200C4291010UL N
U001
P603B PLUG NPLG-5P133 1 25055149
U001
P7401A SOCKET AS NSAS-10P0158 1 2006391010UL
U001
P7401B PLUG NPLG-5P352 1 25055369

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
