Onkyo P-3000R Service Manual

31/55 PAGE
U001
P7402A SOCKET AS NSAS-10P1439 1 2002E391006UL
U001
P7402B PLUG NPLG-5P352 1 25055369
U001
P7403A SOCKET AS NSAS-10P0035 1 2002391010UL
U001
P901 PLUG NPLG-4P151 1 25055167
U001
P902B CRIMP AS CRIMP SR805_1 1 20799169UL
U001
P903B CRIMP AS 1.8S-SGM-51T-4:BLK50 1 20799186UL
U001
RL601 RELAY NRL-2P5A-DC12-192 1 25065702
U001
S7401 R ENCODE EC20A1820401 1 25065710 N
U001
S7402 PUSH SW NPS-111-S681 1 25035718T
U001
S7403 PUSH SW NPS-111-S681 1 25035718T
U001
S7404 PUSH SW NPS-111-S681 1 25035718T
U001
S7405 PUSH SW NPS-111-S681 1 25035718T
U001
S7406 PUSH SW NPS-111-S681 1 25035718T
U002
U002 U0020 + U0021 + U0022 + U0023 + U0024 + U0025
U002
U0020
DIGITAL PC Board BADG-0573-1B/ 1C
U002
U0021
D/A & POWER SUPPLY PC Board BAAR-0574-1B/ 1C
U002
U0022
POWER SWITCH PC Board BASW-0575-1B/ 1C
U002
U0023
VOLUME PC Board BAETC-0589-1B/ 1C
U002
U0024
I/V (Lch) PC Board BAAF-0593-1B/ 1C
U002
U0025
I/V (Rch) PC Board BAAF-0594-1B/ 1C
U002
U002
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U002
[SEMI CONDUCTOR]
U002
D1000 C-DIODE 1SS352 1 223234R2
U002
D1001 C-DIODE 1SS352 1 223234R2
U002
D1002 C-DIODE 1SS352 1 223234R2
U002
D1003 C-DIODE 1SS352 1 223234R2
U002
D1004 C-DIODE 1SS352 1 223234R2
U002
D1005 C-DIODE 1SS352 1 223234R2
U002
D1006 C-DIODE 1SS352 1 223234R2
U002
D1007 C-DIODE S1NB60-4062 1 22380318R2
U002
D1008 C-DIODE S1NB60-4062 1 22380318R2
U002
D1009 C-DIODE S1NB60-4062 1 22380318R2
U002
D1010 C-DIODE S1NB60-4062 1 22380318R2
U002
D1011 C-DIODE 1SS352 1 223234R2 <B MPP, B MDC>
U002
D1012 ZENER D UDZS12B 1 224551200R2 <B MPP, B MDC>
U002
D1013 C-DIODE 1SS352 1 223234R2 <B MPP, B MDC>
U002
D1014 C-DIODE 1SS352 1 223234R2 <B MPP, B MDC>

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
