Onkyo P-3000R Service Manual

32/55 PAGE
U002
D1015 ZENER D UDZS2.0B 1 224550200R2 N
U002
D1016 ZENER D UDZS2.0B 1 224550200R2 N
U002
D4301 ZENER D UDZS5.6B 1 224550560R2
U002
D4401 ZENER D UDZS5.6B 1 224550560R2
U002
D4701 ZENER D UDZS5.6B 1 224550560R2
U002
D4702 ZENER D UDZS5.6B 1 224550560R2
U002
D4703 ZENER D UDZS5.6B 1 224550560R2
U002
D4704 ZENER D UDZS5.6B 1 224550560R2
U002
D4901 DIODE RBV402 1 22380022F
U002
D4902 ZENER D UDZS15B 1 224551500R2
U002
D4903 ZENER D UDZS15B 1 224551500R2
U002
D4904 DIODE RBV402 1 22380022F
U002
D9302 C-DIODE 1SS352 1 223234R2
U002
D9302 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9302 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9302 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9303 C-DIODE 1SS352 1 223234R2
U002
D9303 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9303 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9303 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9304 C-DIODE 1SS352 1 223234R2
U002
D9304 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9304 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9304 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9305 C-DIODE 1SS352 1 223234R2
U002
D9305 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9305 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9305 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9306 C-DIODE 1SS352 1 223234R2
U002
D9306 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9306 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9306 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9307 C-DIODE 1SS352 1 223234R2
U002
D9307 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9307 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9307 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9308 C-DIODE 1SS352 1 223234R2
U002
D9308 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9308 or C-DIODE MA2J111 ( 1) 223279R2

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
