Onkyo P-3000R Service Manual

33/55 PAGE
U002
D9308 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9309 C-DIODE 1SS352 1 223234R2
U002
D9309 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9309 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9309 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9310 C-DIODE 1SS352 1 223234R2
U002
D9310 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9310 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9310 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9311 C-DIODE 1SS352 1 223234R2
U002
D9311 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9311 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9311 or C-DIODE KDS4148U ( 1) 223283R2
U002
D9312 C-DIODE 1SS352 1 223234R2
U002
D9312 or C-DIODE 1SS355 ( 1) 223269R2
U002
D9312 or C-DIODE MA2J111 ( 1) 223279R2
U002
D9312 or C-DIODE KDS4148U ( 1) 223283R2
U002
Q1006 TR 2SC2712-GR 1 2213145R2
U002
Q1006 or TR KTC3875-GR ( 1) 2216175R2
U002
Q1007 IC XC6220B331MR-G 1 22242681R2 N
U002
Q1008 IC XC6220B331MR-G 1 22242681R2 N
U002
Q1009 PHT CP PS2501AL-1 1 24120141R2
U002
Q1010 IC PM39LV512 1 22242679R3 N
U002
Q1011 PHT CP PS2501AL-1 1 24120141R2
U002
Q1012 TR DTA114YKA 1 2216480R2
U002
Q1012 or TR KRA107S ( 1) 2216350R2
U002
Q1013 IC ADUM3440 1 22242678R2 N
U002
Q1014 TR DTC114EKA 1 2216250R2
U002
Q1014 or TR KRC102S ( 1) 2216190R2
U002
Q1015 IC S-812C50AUA-C3E 1 22242240R2
U002
Q1016 TR DTC114EKA 1 2216250R2
U002
Q1016 or TR KRC102S ( 1) 2216190R2
U002
Q1017 TR DTA114YKA 1 2216480R2
U002
Q1017 or TR KRA107S ( 1) 2216350R2
U002
Q1018 TR SI2301CDS 1 2217507R2 N
U002
Q1019 IC CM6631 1 22242676R3 N
U002
Q1020 IC (MAIN MICROPROCESSOR) R5F364AKNFA(0394) 1 222W0111R303940
U002
Q1022 IC R1EX24016ASAS0A 1 22242675R2
U002
Q1023 IC NJU7706F27A3 1 22242614R2

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
