Onkyo P-3000R Service Manual

35/55 PAGE
U002
Q4411 TR 2SA1360-Y 1 2202094
U002
Q4412 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4413 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4414 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4502 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4503 TR 2SA1200-Y(2LONK,ZE) 1 2217584R2
U002
Q4504 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4505 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4506 TR 2SC2880-Y(2LONK,ZE) 1 2217594R2
U002
Q4507 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4509 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4510 TR 2SC3423-Y 1 2202104
U002
Q4511 TR 2SA1360-Y 1 2202094
U002
Q4512 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4513 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4514 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4602 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4603 TR 2SA1200-Y(2LONK,ZE) 1 2217584R2
U002
Q4604 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4605 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4606 TR 2SC2880-Y(2LONK,ZE) 1 2217594R2
U002
Q4607 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4609 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4610 TR 2SC3423-Y 1 2202104
U002
Q4611 TR 2SA1360-Y 1 2202094
U002
Q4612 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4613 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4614 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4701 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4702 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4703 TR 2SC3423-Y 1 2202104
U002
Q4704 TR 2SC3423-Y 1 2202104
U002
Q4705 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4706 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4707 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4708 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4709 TR 2SA1360-Y 1 2202094
U002
Q4710 TR 2SA1360-Y 1 2202094
U002
Q4711 TR 2SC3324-GR(TE85L_F) 1 2216825R2

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
