Onkyo P-3000R Service Manual

36/55 PAGE
U002
Q4712 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4713 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4714 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4715 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4716 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4717 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4718 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4719 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4720 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4721 TR 2SC3423-Y 1 2202104
U002
Q4722 TR 2SC3423-Y 1 2202104
U002
Q4723 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4724 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4725 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4726 TR 2SC3324-GR(TE85L_F) 1 2216825R2
U002
Q4727 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4728 TR 2SA1312-GR(TE85L_F) 1 2216835R2
U002
Q4729 TR 2SA1360-Y 1 2202094
U002
Q4730 TR 2SA1360-Y 1 2202094
U002
Q4901 IC UPC29M05AHF-AZ 1 22278005ENE
U002
Q4902 IC MPC29M33HF 1 22278033ENE
U002
Q4904 IC MPC29M33HF 1 22278033ENE
U002
Q4905 TR 2SA1488-Y 1 2203394
U002
Q4905A HEAT-SINK HEAT-SINK 1 27160179
U002
Q4905B SCREW 3TTB+8B(3CM)SR 1 801637
U002
Q4906 TR 2SK365-GR 1 2212445T
U002
Q4907 TR 2SC1815-GR 1 2211255T
U002
Q4908 TR 2SA1015-GR 1 2211455T
U002
Q4909 TR 2SK365-GR 1 2212445T
U002
Q4910 TR 2SC3851-Y 1 2203384
U002
Q4910A HEAT-SINK HEAT-SINK 1 27160179
U002
Q4910B SCREW 3TTB+8B(3CM)SR 1 801637
U002
Q4911 IC MPC29M33HF 1 22278033ENE
U002
Q4912 IC UPC29M05AHF-AZ 1 22278005ENE
U002
Q9301 TR DTC123JKA 1 2216690R2
U002
Q9301 or TR RN1405 ( 1) 2214500R2
U002
Q9302 IC NJU7706F27A3 1 22242614R2
U002
[CHASSIS SCREW]
U002
E4001 TRM-423(SCREW) NEJITANSI ST3 1 25060495 <B MPP, B MDC>

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
