Onkyo P-3000R Service Manual

37/55 PAGE
U002
E4002 RETAINER (BUS-BAR) 1 27142221
U002
P1029 RETAINER (RI) 1 27142224 N
U002
[TRANS COIL]
U002
L1007 COIL DA102C 1 232205 N
U002
L1008 COIL DA102C 1 232205 N
U002
L1009 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1010 COIL DA102C 1 232205 N
U002
L1011 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1012 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1013 COIL DA102C 1 232205 N
U002
L1014 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1015 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1017 CHOKE COIL LBC2518T4R7M 1 231364M047R2
U002
L1018 CHOKE COIL BLM21PG221SN1 1 230949R2
U002
L1019 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1020 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1023 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1026 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1028 EMIFIL BK1608LM182-T 1 230958R1
U002
L1029 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1030 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1031 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1032 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1033 EMIFIL BK1608LL680-T 1 2350013R1
U002
L1034 EMIFIL BK1608LL680-T 1 2350013R1
U002
T9301 P TRANS NPT-1520JQ 1 2301812A <B MDC>
U002
T9301 P TRANS NPT-1520GQ 1 2301813A <B MPP>
U002
[CAPACITOR]
U002
C1001 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1002 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1003 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1004 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1005 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1006 UTSP C CE04W10V-100M(UTSP) 1 397531017T
U002
C1007 UTSP C CE04W10V-100M(UTSP) 1 397531017T
U002
C1008 UTSP C CE04W10V-100M(UTSP) 1 397531017T
U002
C1009 C-CERA C CK725F1A-105Z1 1 332181050R1
U002
C1010 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1011 C-CERA C CK725F1E-104Z1 1 332161040R1

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
