Onkyo P-3000R Service Manual

40/55 PAGE
U002
C1111 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1112 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1113 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1114 UTSP C CE04W25V-100M(UTSP) 1 397551017T <B MPP, B MDC>
U002
C1115 C-CERA C CK725B1H-103K1 1 332101035R1 <B MPP, B MDC>
U002
C1120 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1121 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1122 UTSP C CE04W10V-470M(UTSP) 1 397534717T
U002
C1123 UTSP C CE04W10V-470M(UTSP) 1 397534717T
U002
C1124 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
C1125 UTSP C CE04W50V 47M(UTSP) 1 397584707T
U002
C4051 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4052 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4061 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4062 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4201 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4202 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4204 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4205 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4206 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4207 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4208 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4209 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4210 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4211 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4212 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4213 ROB C CE04W25V-47M(ROB) 1 395854707T
U002
C4214 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4215 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4216 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4217 UTSP C CE04W10V-220M(UTSP) 1 397532217T
U002
C4218 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4300 UTSP C CE04W25V-47M(UTSP) 1 397554707T
U002
C4301 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4302 C-CERA C CC725CH1H-330J1 1 342103304R1
U002
C4303 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4304 C-CERA C CC725CH1H-471J1 1 342104714R1
U002
C4305 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4400 UTSP C CE04W25V-47M(UTSP) 1 397554707T

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
