Onkyo P-3000R Service Manual

41/55 PAGE
U002
C4401 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4402 C-CERA C CC725CH1H-330J1 1 342103304R1
U002
C4403 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4404 C-CERA C CC725CH1H-471J1 1 342104714R1
U002
C4405 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4501 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4502 C-CERA C CC725CH1H-330J1 1 342103304R1
U002
C4503 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4504 C-CERA C CC725CH1H-471J1 1 342104714R1
U002
C4505 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4601 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4602 C-CERA C CC725CH1H-330J1 1 342103304R1
U002
C4603 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4604 C-CERA C CC725CH1H-471J1 1 342104714R1
U002
C4605 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4701 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4702 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4703 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4704 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4705 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4706 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4707 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4708 UPZ C 2AUPZTF681JE 1 376336814T
U002
C4709 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4710 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4713 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4714 UTSP C CE04W50V-22M(UTSP) 1 397582207T
U002
C4715 MKT C B32529C0332J289 1 376493324T
U002
C4715 or UMXR C 1HUMXRTF332JE ( 1) 376523324T
U002
C4716 MKT C B32529C0332J289 1 376493324T
U002
C4716 or UMXR C 1HUMXRTF332JE ( 1) 376523324T
U002
C4901 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4902 UTSP C CE04W16V-470M(UTSP) 1 397544717T
U002
C4903 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4904 UTSP C CE04W16V-470M(UTSP) 1 397544717T
U002
C4905 UTSP C CE04W25V-100M(UTSP) 1 397551017T
U002
C4906 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4907 UTSK C CE04W16V-2200M(UTSK) 1 398342227S
U002
C4908 UTSK C CE04W16V-2200M(UTSK) 1 398342227S

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
