Onkyo P-3000R Service Manual

42/55 PAGE
U002
C4910 ELECT C CE69W35V-4700M 1 3504477
U002
C4911 TF C ECQ-V50V-104J 1 374721044T
U002
C4912 TF C ECQ-V50V-104J 1 374721044T
U002
C4913 UTSJ C CE04W25V-47M(UTSJ) 1 398054707AT
U002
C4914 UTSK C CE04W16V-2200M(UTSK) 1 398342227S
U002
C4915 UTSK C CE04W16V-2200M(UTSK) 1 398342227S
U002
C4916 UTSJ C CE04W25V-47M(UTSJ) 1 398054707AT
U002
C4918 TF C ECQ-V50V-104J 1 374721044T
U002
C4919 ELECT C CE69W35V-4700M 1 3504477
U002
C4920 TF C ECQ-V50V-104J 1 374721044T
U002
C4921 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4922 UTSP C CE04W16V-470M(UTSP) 1 397544717T
U002
C4923 UTSP C CE04W16V-470M(UTSP) 1 397544717T
U002
C4924 C-FILM C ECHU16V-104J 1 373041044R2
U002
C4928 UTSP C CE04W25V-100M(UTSP) 1 397551017T
U002
C4929 UTSP C CE04W25V-100M(UTSP) 1 397551017T
U002
C4930 TF C ECQ-V50V-104J 1 374721044T
U002
C4931 TF C ECQ-V50V-104J 1 374721044T
U002
C4932 TF C ECQ-V50V-104J 1 374721044T
U002
C4933 TF C ECQ-V50V-104J 1 374721044T
U002
C7414 C-CERA C CC725CH1H-102J1 1 342101024R1 <B MPP, B MDC>
U002
C7415 C-CERA C CC725CH1H-102J1 1 342101024R1 <B MPP, B MDC>
U002
C7421 C-CERA C CC725CH1H-102J1 1 342101024R1 <B MPP, B MDC>
U002
C7427 C-CERA C CC725CH1H-102J1 1 342101024R1 <B MPP, B MDC>
U002
C9303 IS C RE275V-103M 1 3500196S
U002
C9304 TF C ECQ-V50V-104J 1 374721044T
U002
C9305 IS C RE275V-103M 1 3500196S
U002
C9307 TF C ECQ-V50V-104J 1 374721044T
U002
C9308 UTSK C CE04W16V-2200M(UTSK) 1 398342227S
U002
C9309 TF C ECQ-V50V-104J 1 374721044T
U002
C9310 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
U002
C9311 UTSP C CE04W25V-470M(UTSP) 1 397554717T <B MPP, B MDC>
U002
C9312 C-CERA C CK725F1E-104Z1 1 332161040R1
U002
X1006 CRYSTAL HQST-3H2-12000-16 1 3010365T
U002
X1007 CRYSTAL FCXO-05-49.152M 1 3010498R2 N
U002
X1008 CRYSTAL FCXO-05-45.158M 1 3010499R2 N
U002
X1010 CERA LOCK CSTCR6M0055-R0 1 3010397R2
U002
X1011 CRYSTAL HC-49US24.576MHz 1 3010490T
U002
[RESISTOR]

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
