Onkyo TX-8020B - Schematic Diagrams - Part 6 (Headphone Jack); Headphone Jack Circuitry Details; Headphone Signal Routing

TX-8020
SCHEMATIC DIAGRAMS-06(PART-6)
PHONE JACK SECTION
TX-8020
TITLE
APPROVCHECKDESIGN SHEET
DRAWING No.
HP_L
GND
HP-R
GNDMPU
HP_SW
104Z
C5503
104Z
C5505
102J
C5502
102J
C5501
104Z
C5504
D5501
1SS352
D5502
1SS352
P5501
MSJ-064-05A SR
1
2
3
4
5
7
8
BK1608LM182-TL5501
BK1608LM182-TL5502
BK1608LM182-TL5503
E5501
NEJITANSI ST3
1 2 3
4
P503A
NSCT-7P878
1234
56
7
BAETC-1440
HP JACK
HEAD PHONE
2009991320UL
NSAS-7P2131
SCHEMATIC DIAGRAMMODEL NO. TX-8020 (PART-6)
HEAD PHONE_SECTION
TO BATRM-1473
TX-8020
Head Phone Section (Part-6)
RC-202985
T.Ito
2013.04.09
K.Ikeda
2013.04.09
S.Murayama
2013.04.09
6 14
U0014 PHONE JACK PC BOARD
A
1
2
3
4
B C D E
