TX-8522
U013 Thermal detector PCB AS NAETC-8878-1A/1B/1C
U014 Holder PCB NAETC-8879-1A/1B/1C
U015 Primary circuit PCB AS NAPS-8880-1A/1B/1C
U016
Transformer terminal PCB AS
NAETC-8881-1A/1B/1C
U017 Headphone terminal PCB AS NAETC-8882-1A/1B/1C
U018 Video terminal PCB AS NAVD-8883-1A/1B/1C
Q852 FL TUBE 16-BT-128GNYK 212258A
Q251 IC LA7956-E 22241759
Q601 IC M3062LFGPFP U5 or W0048R301910M101 or
Q601 or IC M30624FGPFP W0007R301910M101
NSP
Q701 IC S-812C56AUA-C3K 22242207R2
Q706 IC 78M56(NJM78M56FA) 222780565JRC
Q711 IC S-812C53AUA-C3HT2G 22242270R2
<D/C>
Q712 IC 74HC4052AF 222740525R2
<D/C>
Q851 IC M66005-0001AHP 22242208R3
Q855 IC LM61CIZ 22242212
Q252 TR 2SA1162-GR 2214375R2
Q253 TR 2SC2878-A(TPE2_F) 2212285
Q254 TR RN1404 2214490R2
Q602,Q703 TR RN1404 2214490R2
Q603,Q705 TR RN2402 2214530R2
Q710 TR 2SA1930(ONK_Q) 2203000
<D/C>
Q853 TR 2SC2712-GR 2213145R2
Q854 TR RN1441 2215410R2
Q912 TR KTC3199-GR 2215864
D251,D252 C-DIODE 1SS352 or 223234R2 or
D601,D602,D603 C-DIODE 1SS355 223269R2
D604 ZENER D UDZS5.1B 224550510R2
D701,D702,D703 C-DIODE 1SS352 or 223234R2 or
D704,D705,D706 C-DIODE 1SS355 223269R2
D707,D708,D713 C-DIODE 1SS352 or 223234R2 or
D901,D902,D903 C-DIODE 1SS355 223269R2
D709,D710 DIODE RL1N4003 22380260
<D/C>
D711,D712 ZENER D UDZS5.1B 224550510R2
<D/C>
D851 ZENER D UDZS8.2B 224550820R2
D852 LED SEL2E10C 225374
D853 LED SLI-343URC-TE7 225449
D854 SPCF D SIR-34ST3F 225456
D904,D905,D906 C-DIODE 1SS352 or 223234R2 or
D908,D909 C-DIODE 1SS355 223269R2
D912,D913 C-DIODE 1SS352 or 223234R2 or
D991,D992 C-DIODE 1SS355 223269R2
D914 ZENER D UDZS5.1B 224550510R2
L251 CHOKE COIL NCH-1471 231237K022R2
L701,L857 CHOKE COIL NCH-1479 231237K470R2
L702,L852 CHOKE COIL NCH-1471 231237K022R2
L853,L854,L855 CHOKE COIL NCH-1477 231237K220R2
T902
P TRANS NPT-1520JQ 2301812
! <D/C>
P TRANS NPT-1519GQ 2301811
! <P/A>
U851 REMO SENS NJL34H380A 241365
X601
CERA LOCK CSTLS6M00G-56-A0 or 3010427 or
CERA LOCK CR06000-TG-A0R 3010433
C251,C253 VR C CE04W50V-2.2M(VR) 394680227
C252,C254 VR C CE04W16V-470M(VR) 394644717
C255 VR C CE04W35V-47M(VR) 394664707
C256,C257 C-CERA C CK725F1H-223Z1 332152230R1
C258,C259 C-CERA C CK725F1H-103Z1 332151030R1
C601,C602,C603 C-CERA C CK725F1H-104Z1 332151040R1
C604,C605 C-CERA C CC725CH1H-101J1 342101014R1
C606,C607,C609 C-CERA C CK725F1H-104Z1 332151040R1
C610,C611,C612 C-CERA C CK725F1H-104Z1 332151040R1
C613,C614,C615 C-CERA C CK725B1H-102K1 332101025R1
C616,C617,C618 C-CERA C CK725B1H-102K1 332101025R1
C619,C620 C-CERA C CK725B1H-102K1 332101025R1
C621,C622 C-CERA C CK725F1H-104Z1 332151040R1
C623 VR C CE04W50V-4.7M(VR) 394680477
C701,C711,C719 C-CERA C CK725F1H-104Z1 332151040R1
C702,C703 VR C CE04W16V-100M(VR) 394641017
