Onkyo TX-NR616 Service Manual

1/91 PAGE
TX-NR616
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List.
(B) : Black model
(S) : Silver model
<MDC> : 120V,Canadian model
<MDF> : 120V,Taiwanese model
<MMP> : 220-240V,CE(European) country model
<MMA> : 220-240V,Australian model
<MMB> : 220-240V,UK model
<MMQ> : 220-240V,Hong kong model
<MMR> : 220-240V,Chinese model
TX-NR616
EXPLODED VIEW PARTS LIST
REF. NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
Q6050 TR 2SC5198-O 1 2203063 <B MDC, MDF, MMA, MMQ, MMR>
Q6050 or TR 2SC5198-R ( 1) 2203062 <B MDC, MDF, MMA, MMQ, MMR>
Q6050 or TR 2SC4468-O ( 1) 2202523 <B MDC, MDF, MMA, MMQ, MMR>
Q6050 or TR 2SC4468-P ( 1) 2202526 <B MDC, MDF, MMA, MMQ, MMR>
Q6050 TR 2SC5242-O 1 2202843 <B MMB, MMP / S MMP>
Q6050 or TR 2SC5242-R ( 1) 2202842 <B MMB, MMP / S MMP>
Q6050 or TR 2SC4468-O ( 1) 2202523 <B MMB, MMP / S MMP>
Q6050 or TR 2SC4468-P ( 1) 2202526 <B MMB, MMP / S MMP>
Q6050A ISO SHEET AC238 2 223024 <B / S>
Q6050B ISO SHEET ISO SHEET 6 223050 <B / S>
Q6051 TR 2SC5198-O 1 2203063 <B MDC, MDF, MMA, MMQ, MMR>
Q6051 or TR 2SC5198-R ( 1) 2203062 <B MDC, MDF, MMA, MMQ, MMR>
Q6051 or TR 2SC4468-O ( 1) 2202523 <B MDC, MDF, MMA, MMQ, MMR>
Q6051 or TR 2SC4468-P ( 1) 2202526 <B MDC, MDF, MMA, MMQ, MMR>
Q6051 TR 2SC5242-O 1 2202843 <B MMB, MMP / S MMP>
Q6051 or TR 2SC5242-R ( 1) 2202842 <B MMB, MMP / S MMP>
Q6051 or TR 2SC4468-O ( 1) 2202523 <B MMB, MMP / S MMP>
Q6051 or TR 2SC4468-P ( 1) 2202526 <B MMB, MMP / S MMP>
Q6052 TR 2SC5198-O 1 2203063 <B MDC, MDF, MMA, MMQ, MMR>
Q6052 or TR 2SC5198-R ( 1) 2203062 <B MDC, MDF, MMA, MMQ, MMR>
Q6052 or TR 2SC4468-O ( 1) 2202523 <B MDC, MDF, MMA, MMQ, MMR>
Q6052 or TR 2SC4468-P ( 1) 2202526 <B MDC, MDF, MMA, MMQ, MMR>
Q6052 TR 2SC5242-O 1 2202843 <B MMB, MMP / S MMP>
Q6052 or TR 2SC5242-R ( 1) 2202842 <B MMB, MMP / S MMP>
Q6052 or TR 2SC4468-O ( 1) 2202523 <B MMB, MMP / S MMP>
Q6052 or TR 2SC4468-P ( 1) 2202526 <B MMB, MMP / S MMP>
Q6053 TR 2SC5198-O 1 2203063 <B MDC, MDF, MMA, MMQ, MMR>
Q6053 or TR 2SC5198-R ( 1) 2203062 <B MDC, MDF, MMA, MMQ, MMR>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

Onkyo TX-NR616 Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Composite video in	5
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display	-
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	620 W
Package weight	13500 g

Weight and Dimensions

Depth	328 mm
Width	435 mm
Height	173.5 mm
Weight	11000 g
