Onkyo TX-NR616 Service Manual

16/91 PAGE
C4400 C-CERA C CK725B1H-102K1 1 332101025R1
C4401 C-CERA C CK725B1H-102K1 1 332101025R1
C4404 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4405 C-CERA C CK725F1E-104Z1 1 332161040R1
C4501 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4502 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4505 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4506 TF C ECQ-V50V-105J 1 374721054T
C4507 C-CERA C CK725F1H-224Z1 1 332152240R1
C4508 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4509 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4510 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C6050 TF C ECQ-V50V-103J 1 374721034T
C6051 TF C ECQ-V50V-103J 1 374721034T
C6052 TF C ECQ-V50V-103J 1 374721034T
C6053 TF C ECQ-V50V-103J 1 374721034T
C6054 TF C ECQ-V50V-103J 1 374721034T
C6055 TF C ECQ-V50V-103J 1 374721034T
C6056 TF C ECQ-V50V-103J 1 374721034T
C6301 C-CERA C CK725F1E-104Z1 1 332161040R1
C6351 TF C ECQ-V50V-103J 1 374721034T <B MMA, MMB, MMP, MMQ, MMR>
C6352 TF C ECQ-V50V-103J 1 374721034T <B MMA, MMB, MMP, MMQ, MMR>
C6353 MKT C B32529C0102J289 1 376491024T <B MMA, MMB, MMP, MMQ, MMR>
C6354 MKT C B32529C0102J289 1 376491024T <B MMA, MMB, MMP, MMQ, MMR>
C6401 ELECT C CE69W69V-10000MA 1 3504425
C6401A IB CUSHION W15*3t TAPE 1 28141585
C6402 ELECT C CE69W69V-10000MA 1 3504425
C6403 TF C ECQ-V100V-334J 1 374733344T
C6404 TF C ECQ-V100V-334J 1 374733344T
C6408 C-CERA C CC725CH1H-102J1 1 342101024R1
C6451 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C6452 C-CERA C CK725F1H-104Z1 1 332151040R1
C6453 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6454 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6455 C-CERA C CK725F1H-104Z1 1 332151040R1
C6456 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C950 TF C ECQ-V50V-104J 1 374721044T
C960 VR C CE04W63V-220M(VR) 1 394672217T
C961 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C962 TF C ECQ-V50V-104J 1 374721044T
C963 UTSP C CE04W50V 47M(UTSP) 1 397584707T
[RESISTOR]
R4003 C-CARBON R RN72K1J-331JE 1 435033314R1
R4004 C-CARBON R RN72K1J-331JE 1 435033314R1
R4007 C-CARBON R RN72K1J-331JE 1 435033314R1
R4008 C-CARBON R RN72K1J-331JE 1 435033314R1

Onkyo TX-NR616 Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Composite video in	5
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display	-
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	620 W
Package weight	13500 g

Weight and Dimensions

Depth	328 mm
Width	435 mm
Height	173.5 mm
Weight	11000 g
