Loading...How to enable HDMI CEC on Onkyo Receiver?
To enable HDMI linked operation on your Onkyo Receiver with CEC-compliant devices, first, go to the Setup menu, then navigate to "5. Hardware" - "HDMI" - "HDMI CEC" and set it to "On". Also, ensure that HDMI linking is enabled on the connected CEC-compliant device by checking its instruction manual.
General| Impedance | 6 Ω |
|---|---|
| Receiver type | Surround |
| Audio output channels | 7.2 channels |
| Power output per channel (20-20KHz@8 Ohm) | 175 W |
| HDMI in | 7 |
| AC (power) in | Yes |
| Digital audio optical in | 1 |
| Number of HDMI outputs | 2 |
| Phono inputs (RCA) | 4 |
| Connectivity technology | Wired & Wireless |
| Speakers connectivity type | 6.35 mm/3.5 mm |
| Audio formats supported | AIFF, ALAC, DSD, FLAC, WAV |
| AM band range | 522 - 1611 kHz |
| FM band range | 87.5 - 108 MHz |
| Supported radio bands | AM, FM |
| Preset stations quantity | 40 |
| Internet radio services supported | Amazon Music, Deezer, Spotify, Tidal, TuneIn |
| Optical drive included | No |
| Card reader integrated | - |
| Display | TFT |
| HDCP version | 2.2 |
| Product color | Black |
| Audio decoders | DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD |
| Volume control | Rotary |
| USB 2.0 ports quantity | USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them. |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (standby) | 0.15 W |
| Power consumption (typical) | 570 W |
Weight and Dimensions| Depth | 468 mm |
|---|---|
| Width | 534 mm |
| Height | 265 mm |
| Weight | 12500 g |
