Advanced Settings
23
1.Input/Output Assign
Monitor Out
The video input signals input to the unit will be converted when they are output from the
HDMI OUT jack to the TV so that their resolution can match that of the TV used.
Setting item Default Value Setting Details
Monitor Out MAIN Select the HDMI jack to connect the TV.
"MAIN": When connecting the TV to the HDMI OUT
MAIN jack
"SUB": When connecting the TV to the HDMI OUT
SUB jack
r The resolution of the input signal does not
change when output through HDMI OUT SUB
jack.
"MAIN+SUB": When connecting to both the MAIN
and SUB jacks
r Video signals input to the composite video input
jack or the COMPONENT VIDEO input jacks will
be upconverted to HDMI signals and then output
from the HDMI output jack.
r If "MAIN+SUB" is selected
– Only "Through" or "Auto" can be selected in
"Resolution".
– The resolution of the input signal does not
change when output through HDMI OUT SUB
jack.
r The HDMI jack of this unit is compliant with
HDCP2.2 (HDMI OUT MAIN and HDMI IN3
jacks only).
Setting item Default Value Setting Details
Resolution Through Specify the output resolution of the HDMI OUT
jacks. The image resolution of the unit will be
converted so that it can match the resolution
supported by the TV used.
"Through": The output resolution will be the same
as that of the input signals.
"Auto": The resolution will automatically be
converted according to the resolution supported by
the TV.
"480p (480p/576p)", "720p", "1680×720p", "1080i",
"1080p", "2560×1080p": Select the desired
resolution.
"4K": About four times as high resolution as 1080p
(3840×2160 or 4096×2160 pixels depending on the
resolution supported by the connected TV)
r If "1080p" is selected, 1080p/24 input signals will
be output with an unchanged resolution.
r If the selected resolution is not supported by
the monitor, the video is output in the same
resolution as the input signal.
r If "4K" is selected, video signals may not be
output to some types of TV. For details, see
"Supported Video Resolution of HDMI OUT
MAIN/SUB Jacks" in "Reference Information".
r If "Monitor Out" is set to "SUB", this setting will
be set to "Through".
r You can check the video on the TV while making
this setting. Select the value with the cursors
and press ENTER. Press RETURN if no video
is displayed. (except when "NET", "USB" or
"BLUETOOTH" is selected)
To Next Page
