Onkyo TX-NR818 User Manual

Appendix
En-111
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (North American)
135 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.08% (FTC)
(Others)
7 ch × 180 W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
Maximum Effective Output Power
(Asian)
7 ch × 230 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
300 W (3 Ω, Front)
250 W (4 Ω, Front)
150 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
200 mV/470 Ω (PRE OUT)
Maximum RCA Output Level and Impedance
4.6 V/470 Ω (PRE OUT)
Phono Overload 70 mV (MM 1 kHz 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
FM Tuning Frequency Range
(North American) 87.5 MHz - 107.9 MHz
(Others) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American) AC 120 V, 60 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American) 8.1 A
(Others) 720 W
No-sound Power Consumption
(North American) 95 W
(Others) 90 W
Stand-by Power Consumption
0.1 W
Dimensions (W × H × D)
435 mm × 198.5 mm × 435.5 mm
17-1/8" × 7-13/16" × 17-1/8"
Weight 18.3 kg (40.3 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7,
AUX INPUT
Output OUT MAIN, OUT SUB
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD)
Component IN 1, IN 2
Composite BD/DVD, CBL/SAT, STB/DVR, GAME 1,
AUX
Analog RGB PC IN
Component MONITOR OUT
Composite MONITOR OUT
Digital Optical: 2 (Rear), 1(Front)
Coaxial: 3
Analog BD/DVD, CBL/SAT, STB/DVR, GAME 1,
PC, TV/CD, PHONO, AUX
Analog ZONE2 LINE OUT, ZONE3 LINE OUT
Analog Multichannel Pre Outputs
9
Subwoofer Pre Outputs
2
Speaker Outputs Main (L, R, C, SL, SR, SBL, SBR) + Front
Wide/ZONE2 (L, R) + Front High/ZONE3
(L, R)
Phones 1 (6.3 ø)
Setup Mic 1
RS232 1
RI 1
USB 1 (Front)/1 (Rear)
Ethernet 1
IR Input 1
IR Output 1
12 V Trigger Out 2

Onkyo TX-NR818 Specifications

General

Impedance	6 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	470 Ω
Pre-out channels	9.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	300 W
Dynamic power per channel (4 Ohm)	250 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Audio (L/R) in	7
Remote (IR) input	1
Composite video in	5
Digital audio optical in	3
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Wi-Fi	No
RDS features	PS, PTY, RT, TP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Last.fm, vTuner
Display	LCD
Product color	Silver
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	720 W
THX-certified	THX Select2 Plus
Package weight	22000 g
Cables included	AC
Card reader integrated	-

Weight and Dimensions

Depth	435.5 mm
Width	435 mm
Height	198.5 mm
Weight	18300 g
