Onkyo TX-RZ830

1/81 PAGE
TX-RZ830(B)MDC
<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
Black color model
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
120V
Therefore, when replacing, be sure to use parts of identical designation.
Canada/USA/(Mexico)
: NSP
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (PN) REMARKS
A001 CHASSIS (2018ENTRY) 1 27100633A N NSP
A002 BOTTOM LEG (FRONT) 2 27175477A N
A003 BOTTOM LEG (REAR) 2 27175478A
A004 CUSHION (CORK)D25*9*T2 4 28141968 NSP
A005 SCREW 3TTB+8B(3BC) 4 838430088GR NSP
A006 HOLDER (CPS-8) 2 27191383 NSP
A006or HOLDER KGLS-8RT (2) 27190503A NSP
A007 HOLDER (NPS-8) 2 27191387 NSP
A007or HOLDER KGPS-8RF (2) 27191044 N NSP
A008 HOLDER (NPS-14) 3 27191388 NSP
A008or HOLDER KGPS-14RF (3) 27190802 NSP
A010 HOLDER (PGS-22) 3 27191382 NSP
A010or HOLDER KGLS-22S (3) 27190369 N NSP
A011 HOLDER (PGS-62) 2 27191450 NSP
A012 HEAT SINK RZ830 1 27160728 N NSP
A013 SPACER (PC) 5 27270485 NSP
A014 SCREW 3P+6FN(3BC) 3 82143006GR NSP
A015 RETAINER (HR)TX-NR656 1 27142349 NSP
A016 RETAINER (HL)TX-NR656 1 27142350 NSP
A019 SCREW 3SMH10W.SW+15B(CU) 18 801606 NSP
A020 SCREW 3TTB+8B(3BC) 4 838430088GR NSP
A021 SCREW 3TTB+8B(3BC) 1 838430088GR NSP
A022 SCREW 3TTB+8B(3BC) 2 838430088GR NSP
A023 SCREW 3TTB+8B(3BC) 2 838430088GR NSP
A024 RETAINER (B) 1 27142141A NSP
A025 SCREW 3TTB+8B(3BC) 2 838430088GR NSP
A026 SCREW 3TTB+8B(3BC) 1 838430088GR NSP
A027 SCREW 3TTB+8B(3BC) 3 838430088GR NSP
A028 SCREW 3TTB+8B(3CM)SR 3 801637 NSP
A029 RETAINER (PS) 1 27142382A N NSP
A030 SCREW 3TTB+8B(3BC) 3 838430088GR NSP
A031 SCREW 4TTC+8C(3BC)SR 4 801658 NSP
A032 HOLDER (ANNTENA-1) 1 27191416 NSP
A033 HOLDER (ANNTENA-2) 1 27191417 NSP
A036A LABEL (E-CON) 1 29364978 NSP
A037 WIRE TIE BSK-1 8 260208 NSP
A038 TAPE TAPE(CLOTH-16U) 0.1 29110083 NSP
A039 BRACKET (F)RZ830 1 27131195 N NSP
A040 SCREW 3TTB+8B(3BC) 6 838430088GR NSP
A041 LABEL (PT)ONKYO 1 29392594 NSP
A042 BRACKET (FAN)727 1 27131133B NSP
A043 BUSHING (FAN-L) 4 28170091A NSP
A044 CUSHION (FELT)t1x20x10 4 28141859 NSP
A046 RETAINER (HDMI) 1 27142383 N NSP
[ Cabinet, Chassis, Screws, Nuts ]
