Onkyo TX-RZ830

5/81 PAGE
A810 WARRANTY CARD (ONKYO RZ-SERIES) 1 29365230A
A901 SHEET FLYER(ONKYOMUSIC18) 1 29380179A NSP
A902 INSTRUCTION MANUAL QSG_U8(TXRZ830) 1 29403383 N
A904 INSTRUCTION MANUAL SAFETY_U4(2018 Light-ONK) 1 29403355A N
A905 SHEET FLYER-US NCP2017 1 29380177 NSP
A910 INSTRUCTION MANUAL (Chromecast built-in_Onk_U8) 1 29403203
P9001 POWER SUPPLY CORD AS-UC-2 1 253352ATES !
BAAF-2597-1N
<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
Silver color model
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
220-240V
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (PN) REMARKS
D4401 ZENER DIODE DZ2J100M0L 1 224761000R2 NSP
D4402 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D4403 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D4404 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D4701 DIODE RL1N4003 1 22380260T NSP
D4702 DIODE RL1N4003 1 22380260T NSP
D4703 DIODE RL1N4003 1 22380260T NSP
D4704 DIODE RL1N4003 1 22380260T NSP
D4705 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D4706 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D4707 ZENER DIODE DZ2J075M0L 1 224760750R2 NSP
D4708 ZENER DIODE DZ2J075M0L 1 224760750R2 NSP
D5085 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D5086 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D5087 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D5088 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D5089 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D5090 ZENER DIODE DZ2J056M0L 1 224760560R2 NSP
D6601 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6601or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6602 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6602or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6603 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6603or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6605 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6605or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6606 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6606or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6607 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6607or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6608 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D6608or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D6609 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
[ Semi-conductors ]
