Onkyo TX-RZ830

40/81 PAGE
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (PN) REMARKS
Q8500 HYBRID IC TCA9517DGKR 1 22243201R2 NSP
L8505 CORE BLM15PX181SN1D 1 2350033R1 NSP
C8501 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K1 1 332101025R1 NSP
C8502 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K1 1 332101025R1 NSP
C8503 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1 NSP
C8505 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K0 1 332031035R1 NSP
R8503 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1 NSP
R8504 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1 NSP
R8505 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1 NSP
R8506 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1 NSP
R8507 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1 NSP
P130 PRINTED WIRING BOARD BCHDM-2038 1 25142038 NSP
P8500 SOCKET SNN04SBB2200-84R 1 25053613R2 NSP
P8501 SOCKET SNN15SBA4600-84R 1 25053587R2 NSP
P8502B TERMINAL NTM-1P233(M1969) 1 25060302 NSP
BAPRC-2605-1H
<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
Silver color model
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
220-240V
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (PN) REMARKS
D7001 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D7001or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D7002 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D7002or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D7003 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D7003or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D7004 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D7004or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D7006 DIODE CUS357 1 223320R2 NSP
D7009 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D7009or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
D8003 ESD IMSA-6802-01Y901_1608SIZE 1 4000255AR1 NSP
D8900 DIODE CUS357 1 223320R2 NSP
D8901 DIODE CUS357 1 223320R2 NSP
D8902 DIODE CUS357 1 223320R2 NSP
D8907 CHIP TYPE DIODE DA2J10100 1 223303R2 NSP
D8907or CHIP TYPE DIODE 1SS352 (1) 223234R2 NSP
[ Semi-conductors ]
[ Transformers, Coils ]
[ Capacitors ]
[ Resistors ]
[ Switches, Terminals, Wires ]
[ Semi-conductors ]
