Onkyo TX-RZ830

THERMAL SENSOR SECTION
TX-NR787/RZ630/RZ730/RZ830,DRX-3.2/4.2/5.2
1
A
B
C
D
E
2 3 4 5 6
1 2 3 4 5 6
A
B
C
D
E
+3.3VDC
+3.30V
+3.3VDC
GNDDG
THERMAL
PTC
C6801
NM
Q6800A
(PTH)
1 2
104Z
C6800
25V
P6800A CHD-1.5-5
1 2 3 4 5
R6803
47k
F_+-1%
R6805
82k
F_+-1%
R6801
NM
R6804
180k
104Z
C6802
25V
NM
R6807
NM
F_+-1%
R6808
220k
R6802
15k
F_+-1%
R6806
470
Q6800
LM61CIZ
G
O
V
Q6801
2SC2712-GR
Q6802
2SA1162-GR
TP6300
Thermal
connect
PRC
FROM BAPRC-2387(PART-14)
THERMAL
BAETC-2598
Schematic Diagrams
