Onkyo TX-RZ830 - DISPLAY(ENCODER)SECTION

DISPLAY(ENCODER)SECTION
TX-RZ830
1
A
B
C
D
E
2 3 4 5 6
1 2 3 4 5 6
A
B
C
D
E
LMDB
LMDA
TONEA
TONEB
KEY0_1
+3.3VS
KEY0
LEDPURE
GND_DG
KEY3_1
KEY3
P7591B
CHD-1.5-11
1 2 3 4 5 6 7 8 9 1011
Q7751
KRC105S
102K
C7601
R7601
270
R7631
270
R7751
680
S7740
XREB125(9X11.5)PVB30FINB1-2-24
1 3
4 5
2
S7774
XREB125(9X11.5)PVB30FINB1-2-24
1 3
4 5
2
S7602
NPS-111-S681
S7632
NPS-111-S681
S7631
NPS-111-S681
S7601
NPS-111-S681
D7602
NC
D7601
NC
D7751
QL3P-BB41-M0000
KEY
BASW-2578
STANDBY
PURE AUDIO
TO BADIS-2575-2(Page 20/60)
DISPLAY
PURE AUDIO(Blue)
LISTENING MODE
TONE
Chassis GND
レジスト剥ぎ
LISTENING MODE
TONE
NPS-111-S681 or NPS-111-S677(25035714T)
S7601/7602/7631/7632
(LED)LH-5-2
(27191336)
D7751A
P7591B:or NSCT-12P883(25051095)
or DTC123JCAT116
(2219040R2)
w/ click w/ click
Schematic Diagrams
