Onkyo TX-RZ830 - DISPLAY(MIC,HEAD PHONE)SECTION

DISPLAY(MIC,HEADPHONE)SECTION
DRX-5.2
1
A
B
C
D
E
2 3 4 5 6
1 2 3 4 5 6
A
B
C
D
E
HPR
HPL
HP_GND
HPDET
GND_DG
MICDET_1
GNDAUX
MICIN_1
102J
C7884
50V
P7850
MSJ-035-12A-B-AG-PBT(OC257)
2
3
1
R7859
22k
L7850
NM
P7851B
NPLG-3P131
123
104Z
C7857
25V
D7855
DA2J10100
D7856
DA2J10100
223K
C7880
50V
103K
C7883
50V
C7881
221J 100V
C7882
221J
100V
P7880A
NPLG-5P119
12345
P7881
MSJ-064-05A GR
1
2
3
4
5
7
8
R7881
1/2W330
R7880
1/2W
330
TO TRM
TO BATRM-2607(Page 11/60)
HEADPHONE
BAETC-2592
TO BCDIS-2588(Page 27/60)
DISPLAY
MIC
Schematic Diagrams
